LAM 810-225831-001電源驅動器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
LAM 810-225831-001 電源驅動器卡 是泛林半導體（LAM Research）設備中關鍵的電源管理模塊之一，專用于驅動和控制電源分配。此模塊通常集成在半導體制造設備的電源控制系統中，負責對多個子系統提供穩定的電源，并進行動態調節，以滿足設備運行的功率需求。
產品特點
精確的電源控制：
- 提供高精度的電源驅動能力，支持動態調整電壓和電流輸出。
- 適用于復雜設備的多路電源分配需求。
高可靠性：
- 工業級設計，能夠在高負載和復雜工況下穩定運行。
- 提供內置過壓、過流、過溫等保護功能，保障設備安全。
模塊化設計：
- 緊湊型卡式結構，易于安裝和更換。
- 與 LAM 系統的其他模塊兼容性強，支持即插即用。
實時監控：
- 內置電源狀態監測功能，可實時反饋電壓、電流參數。
- 支持快速診斷故障，提升維護效率。
寬輸入范圍：
- 支持多種輸入電壓規格，適應全球各地的電力標準。
技術規格（假設參考）
| 參數 | 說明 |
|---|---|
| 輸入電壓范圍 | 200-240 VAC 或 24-48 VDC |
| 輸出電壓范圍 | 5V / 12V / 24V（具體值需確認） |
| 最大輸出功率 | 300W - 500W（需根據具體應用確認） |
| 輸出通道數 | 多通道輸出（如 4-8 通道） |
| 工作頻率 | 50/60 Hz |
| 保護功能 | 過流、過壓、過溫保護 |
| 接口類型 | 標準插槽接口 |
| 工作溫度范圍 | 0°C 至 70°C |
| 尺寸 | 卡式模塊，符合標準插槽規格 |
| 認證 | CE、UL、FCC 或其他行業認證 |
英文資料：
The LAM 810-225831-001 power driver card is one of the key power management modules in LAM Research equipment, dedicated to driving and controlling power distribution. This module is usually integrated into the power control system of semiconductor manufacturing equipment, responsible for providing stable power to multiple subsystems and dynamically adjusting to meet the power requirements of equipment operation.
Product Features
Accurate power control:
Provide high-precision power drive capability and support dynamic adjustment of voltage and current output.
Suitable for the multi-channel power distribution requirements of complex devices.
High reliability:
Industrial grade design, capable of stable operation under high loads and complex working conditions.
Provide built-in protection functions such as overvoltage, overcurrent, and overtemperature to ensure equipment safety.
Modular design:
Compact card structure, easy to install and replace.
Strong compatibility with other modules of LAM system, supporting plug and play.
Real time monitoring:
Built in power status monitoring function, which can provide real-time feedback on voltage and current parameters.
Support rapid fault diagnosis and improve maintenance efficiency.
Wide input range:
Supports multiple input voltage specifications and adapts to power standards around the world.
Technical specifications (assuming reference)
Parameter Description
Input voltage range 200-240 VAC or 24-48 VDC
Output voltage range 5V/12V/24V (specific values need to be confirmed)
Maximum output power 300W-500W (to be confirmed according to specific application)
Number of output channels: Multi channel output (such as 4-8 channels)
Working frequency 50/60 Hz
Protection functions include overcurrent, overvoltage, and over temperature protection
Interface Type: Standard Slot Interface
Working temperature range: 0 ° C to 70 ° C
Size card module, compliant with standard slot specifications
Certification CE, UL, FCC or other industry certifications
2.產 品 展 示
