GE IS200AEPAH1AFD渦輪控制模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE IS200AEPAH1AFD 渦輪控制模塊 是 GE Mark VI 系列 控制系統的重要組成部分，專用于燃?xì)廨啓C(jī)、蒸汽輪機等旋轉設備的控制和保護。該模塊通過高效的電源分配和信號調節功能，確保渦輪機的安全、穩定和高效運行。
核心功能：
電源分配與管理：
- 接收外部電源輸入，并將穩定電源分配至系統各個模塊。
- 提供電壓調節和過載保護功能，確保電力供應的穩定性和安全性。
信號調節與接口：
- 處理渦輪機傳感器信號（如溫度、壓力、速度等），并將數據傳輸至控制系統。
- 具有強大的抗干擾能力，確保信號準確性與實時性。
高可靠性設計：
- 采用工業級組件，支持長期連續運行，適用于嚴苛環境。
- 提供冗余設計，避免因單點故障導致系統停機。
模塊化架構：
- 可輕松集成到 GE Mark VI 渦輪控制系統中。
- 支持熱插拔功能，簡化系統維護和更換過程，減少停機時間。
技術規格：
- 型號：IS200AEPAH1AFD
- 系統兼容性：GE Mark VI 渦輪控制系統
- 電源管理：
- 輸入電壓：24V DC
- 穩壓輸出：多通道分配
- 信號接口：適配多種傳感器數據輸入
- 工作溫度：-40°C 到 +70°C
- 濕度范圍：5% 到 95%（非冷凝）
- 安裝方式：標準 19 英寸機架安裝
- 冗余支持：支持冗余電源和信號通道
英文資料：
The GE IS200AEPAH1AFD turbine control module is an important component of the GE Mark VI series control system, specifically designed for controlling and protecting rotating equipment such as gas turbines and steam turbines. This module ensures the safe, stable, and efficient operation of the turbine through efficient power distribution and signal conditioning functions.
Core functions:
Power distribution and management:
Receive external power input and distribute stable power to various modules of the system.
Provide voltage regulation and overload protection functions to ensure the stability and safety of power supply.
Signal conditioning and interface:
Process turbine sensor signals (such as temperature, pressure, speed, etc.) and transmit the data to the control system.
Has strong anti-interference ability, ensuring signal accuracy and real-time performance.
High reliability design:
Adopting industrial grade components, supporting long-term continuous operation, suitable for harsh environments.
Provide redundant design to avoid system downtime caused by a single point of failure.
Modular architecture:
Can be easily integrated into the GE Mark VI turbine control system.
Support hot swapping function, simplify system maintenance and replacement process, and reduce downtime.
Technical specifications:
model: IS200AEPAH1AFD
System compatibility: GE Mark VI turbine control system
Power management:
Input voltage: 24V DC
Stable output: multi-channel allocation
Signal interface: compatible with multiple sensor data inputs
Working temperature:- 40 ° C to+70 ° C
Humidity range: 5% to 95% (non condensing)
Installation method: Standard 19 inch rack installation
Redundancy support: Supports redundant power and signal channels
2.產 品 展 示
