CCC TMPU-1002轉換模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
CCC TMPU-1002 轉換模塊 是由 Compressor Controls Corporation (CCC) 設計的工業級信號轉換模塊，專用于工業控制系統中信號處理和轉換，確保數據在不同設備和系統之間高效、精準傳輸。它在壓縮機和渦輪機控制應用中表現突出，廣泛用于石油天然氣、電力、化工等領域。
核心功能：
信號轉換與處理
- 將輸入信號（如模擬信號、數字信號）轉換為系統所需的標準信號格式。
- 確保信號在控制系統中的兼容性與穩定傳輸。
數據傳輸與通信
- 支持多種工業標準通信協議（如 Modbus、Profibus 等），實現與上位機或其他模塊之間的數據交換。
- 提供高效、低延遲的數據傳輸，保障實時控制需求。
信號隔離與保護
- 提供電氣隔離，防止信號干擾，提升系統的抗噪性與可靠性。
- 保護設備免受過電壓和浪涌影響。
模塊化設計
- 緊湊的模塊化設計便于安裝、集成和維護。
- 支持與其他 CCC 控制模塊無縫集成，擴展系統功能。
高可靠性與穩定性
- 工業級設計，適應惡劣環境（高溫、濕度、振動等）。
- 具備長時間穩定運行的能力，減少系統故障風險。
技術規格：
- 型號：TMPU-1002
- 功能：信號轉換與隔離
- 輸入信號：支持多種模擬和數字輸入格式
- 輸出信號：標準工業控制信號（如 4-20mA、0-10V）
- 通信接口：
- Modbus
- Profibus
- 其他工業通信協議
- 電氣隔離：輸入/輸出通道之間提供高效電氣隔離
- 供電電壓：24V DC
- 工作溫度：-40°C 至 +70°C
- 濕度范圍：5% 至 95%（非冷凝）
- 安裝方式：DIN 導軌或機架安裝
- 模塊化設計：支持快速更換與維護
應用領域：
- 壓縮機與渦輪機控制系統
- 提供高精度信號轉換，確?？刂葡到y(tǒng)與傳感器、執行器的兼容性。
- 石油與天然氣行業
- 適用于復雜工藝流程中的數據轉換與傳輸，確保系統穩定運行。
- 化工與電力行業
- 在關鍵工藝控制環節中提供高可靠性的數據傳輸與隔離保護。
- 工業自動化與過程控制
- 實現多設備間的信號轉換與集成，優化自動化控制流程。
英文資料：
The CCC TMPU-1002 conversion module is an industrial grade signal conversion module designed by Compressor Controls Corporation (CCC), dedicated to signal processing and conversion in industrial control systems, ensuring efficient and accurate transmission of data between different devices and systems. It performs outstandingly in compressor and turbine control applications and is widely used in fields such as oil and gas, electricity, and chemical engineering.
Core functions:
Signal Conversion and Processing
Convert input signals (such as analog and digital signals) into the standard signal format required by the system.
Ensure compatibility and stable transmission of signals in the control system.
Data transmission and communication
Support multiple industrial standard communication protocols (such as Modbus, Profibus, etc.) to achieve data exchange with the upper computer or other modules.
Provide efficient and low latency data transmission to ensure real-time control requirements.
Signal isolation and protection
Provide electrical isolation to prevent signal interference and enhance the system's noise resistance and reliability.
Protect equipment from overvoltage and surge effects.
Modular design
The compact modular design facilitates installation, integration, and maintenance.
Support seamless integration with other CCC control modules to expand system functionality.
High reliability and stability
Industrial grade design, suitable for harsh environments such as high temperature, humidity, vibration, etc.
Capable of long-term stable operation, reducing the risk of system failure.
Technical specifications:
model: TMPU-1002
Function: Signal conversion and isolation
Input signal: Supports multiple analog and digital input formats
Output signal: Standard industrial control signal (such as 4-20mA, 0-10V)
Communication interface:
Modbus
Profibus
Other industrial communication protocols
Electrical isolation: Provide efficient electrical isolation between input/output channels
Power supply voltage: 24V DC
Working temperature:- 40 ° C to+70 ° C
Humidity range: 5% to 95% (non condensing)
Installation method: DIN rail or rack installation
Modular design: supports quick replacement and maintenance
Application areas:
Compressor and turbine control system
Provide high-precision signal conversion to ensure compatibility between control systems, sensors, and actuators.
Oil and gas industry
Suitable for data conversion and transmission in complex process flows, ensuring stable system operation.
Chemical and power industries
Provide high reliability data transmission and isolation protection in critical process control links.
Industrial Automation and Process Control
Realize signal conversion and integration between multiple devices, optimize automation control processes.
2.產 品 展 示
