ABB RET543AM243AAAB變壓器終端 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB RET543AM243AAAB 變壓器終端 是一款用于變電站的保護、控制和監控的設備，專為變壓器保護設計。它結合了變壓器保護功能、測量和通訊能力，廣泛應用于電力系統中，確保變壓器的安全、可靠運行。
主要特點：
- 全面保護：提供過流、過壓、接地故障等多種保護功能，確保變壓器在異常情況下的安全運行。
- 靈活配置：支持多種輸入、輸出配置，適應不同變電站和電力系統的需求。
- 高度集成：集成保護、控制、監測和自動化功能，減少系統復雜性，提高可靠性。
- 遠程監控：支持通訊協議如IEC 61850、Modbus等，實現遠程監控和控制。
- 實時診斷：內置自診斷功能，能實時檢測故障并報警，便于維護和快速響應。
- 操作簡便：配備直觀的人機界面，簡化操作，支持本地和遠程操作。
典型應用：
- 變電站：用于變壓器的保護與監控，確保變電站安全、穩定運行。
- 電力系統：在電網中提供變壓器的保護，避免故障傳播。
- 發電廠：監控發電廠中的變壓器，保護設備免受損害。
- 電力配電：在配電網絡中實現變壓器保護與故障診斷。
性能優勢：
- 高可靠性：多重保護功能和實時診斷確保變壓器長期穩定運行。
- 高集成度：集成多個功能模塊，簡化系統架構，降低運維成本。
- 易于維護：提供詳細的故障信息和診斷功能，便于快速排除故障。
- 靈活適應：支持多種通訊協議，易于與其他系統集成。
英文資料：
The ABB RET543AM243AAAB transformer terminal is a device designed specifically for transformer protection, control, and monitoring in substations. It combines transformer protection functions, measurement and communication capabilities, and is widely used in power systems to ensure the safe and reliable operation of transformers.
Main features:
Comprehensive protection: Provides multiple protection functions such as overcurrent, overvoltage, and grounding faults to ensure the safe operation of transformers under abnormal conditions.
Flexible configuration: Supports multiple input and output configurations to meet the needs of different substations and power systems.
Highly integrated: Integrating protection, control, monitoring, and automation functions to reduce system complexity and improve reliability.
Remote monitoring: Supports communication protocols such as IEC 61850, Modbus, etc., to achieve remote monitoring and control.
Real time diagnosis: Built in self diagnostic function, able to detect faults in real time and alarm, easy to maintain and respond quickly.
Easy to operate: equipped with an intuitive human-machine interface, simplifying operations, and supporting local and remote operations.
Typical applications:
Substation: Used for the protection and monitoring of transformers to ensure safe and stable operation of the substation.
Power system: Provide protection for transformers in the power grid to prevent fault propagation.
Power plant: Monitor transformers in the power plant to protect equipment from damage.
Power distribution: Implementing transformer protection and fault diagnosis in the distribution network.
Performance advantages:
High reliability: Multiple protection functions and real-time diagnosis ensure the long-term stable operation of transformers.
High integration: Integrating multiple functional modules, simplifying system architecture, and reducing operation and maintenance costs.
Easy to maintain: Provides detailed fault information and diagnostic functions for quick troubleshooting.
Flexible adaptation: Supports multiple communication protocols and is easy to integrate with other systems.
2.產 品 展 示
