Bently 3500/70M 140734-09動態壓力監測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3500/70M (140734-09) 動態壓力監測器模塊 是一款高度專業化的監測設備，專為實時監測工業設備的動態壓力變化設計。該模塊用于檢測快速變化的壓力信號，如燃氣渦輪、壓縮機或其他高動態壓力設備的振動和沖擊波，以保護設備并提高其運行效率。
產品概述
| 屬性 | 詳情 |
|---|---|
| 型號 | 3500/70M |
| 訂貨號 | 140734-09 |
| 設備類型 | 動態壓力監測器模塊 |
| 系列 | Bently Nevada 3500 系列 |
| 主要功能 | 實時動態壓力監測、分析和報警 |
| 安裝位置 | 安裝在 3500 框架中 |
關鍵特點
動態壓力監測：
- 專為檢測快速變化的壓力信號設計，適合高動態環境。
- 可捕捉與設備運行相關的壓力脈沖、沖擊波和振動信號。
高分辨率信號處理：
- 內置高性能數字信號處理（DSP）單元，可實時分析動態信號。
- 支持頻率范圍寬，適合捕捉高頻壓力變化。
報警和保護功能：
- 配備告警（Alert）和危險（Danger）級別的報警功能。
- 支持報警閾值的自定義設置，以適應不同設備和應用。
多通道輸入：
- 提供多個壓力傳感器輸入通道，每個通道可單獨配置。
- 兼容多種動態壓力傳感器。
模塊化設計：
- 支持熱插拔，方便現場更換或升級，無需停機。
- 可與其他 3500 系列模塊無縫集成，實現完整的設備監測和保護。
數據分析與通信：
- 可與系統控制中心連接，提供實時數據和歷史趨勢記錄。
- 支持數據總線通信，與其他模塊共享數據。
英文資料：
The Bently Nevada 3500/70M (140734-09) Dynamic Pressure Monitor Module is a highly specialized monitoring device designed for real-time monitoring of dynamic pressure changes in industrial equipment. This module is used to detect rapidly changing pressure signals, such as vibrations and shock waves from gas turbines, compressors, or other high dynamic pressure equipment, in order to protect the equipment and improve its operational efficiency.
Product Overview
Attribute Details
Model 3500/70M
Order number 140734-09
Equipment type: Dynamic pressure monitor module
Bently Nevada 3500 Series
Main functions: real-time dynamic pressure monitoring, analysis, and alarm
Installation position: Installed in the 3500 frame
Key features
Dynamic pressure monitoring:
Specially designed for detecting rapidly changing pressure signals, suitable for high dynamic environments.
Can capture pressure pulses, shock waves, and vibration signals related to device operation.
High resolution signal processing:
Built in high-performance digital signal processing (DSP) unit, capable of real-time analysis of dynamic signals.
Supports a wide frequency range, suitable for capturing high-frequency pressure changes.
Alarm and protection functions:
Equipped with Alert and Danger level alarm functions.
Support custom setting of alarm thresholds to adapt to different devices and applications.
Multi channel input:
Provide multiple pressure sensor input channels, each channel can be configured separately.
Compatible with multiple dynamic pressure sensors.
Modular design:
Support hot swapping, convenient for on-site replacement or upgrade, without the need for downtime.
It can seamlessly integrate with other 3500 series modules to achieve complete device monitoring and protection.
Data analysis and communication:
Can be connected to the system control center to provide real-time data and historical trend records.
Support data bus communication and share data with other modules.
2.產 品 展 示
