Bently 3500/77M 176449-07壓力監測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3500/77M (176449-07) 壓力監測器模塊 是一款高性能的監控設備，用于工業應用中的壓力信號監測和分析，提供實時保護和報警功能。此模塊是 3500 系列的一部分，廣泛應用于關鍵設備的狀態監控，特別是在需要高可靠性和精準壓力監測的場景。
產品概述
| 屬性 | 詳情 |
|---|---|
| 型號 | 3500/77M |
| 訂貨號 | 176449-07 |
| 設備類型 | 壓力監測器模塊 |
| 系列 | Bently Nevada 3500 系列 |
| 主要功能 | 實時壓力監測、報警、數據分析與保護 |
| 安裝位置 | 安裝在 3500 框架中 |
關鍵特點
多通道監測：
- 提供多個輸入通道，可同時監測多個壓力點。
- 每個通道獨立配置，滿足復雜的監測需求。
高分辨率信號處理：
- 支持壓力信號的實時采集和高精度處理。
- 集成數字信號處理（DSP）單元，確保數據精度。
報警功能：
- 配備告警（Alert）和危險（Danger）報警級別。
- 報警閾值可自由設置，適配各種設備運行條件。
模塊化設計：
- 支持熱插拔設計，方便在不停止系統運行的情況下進行維護或更換。
- 與 3500 系列其他模塊無縫協作，構建完整監測系統。
數據記錄與分析：
- 支持實時數據輸出，便于分析設備運行狀況。
- 可記錄歷史壓力數據，用于趨勢分析和故障診斷。
適應嚴苛環境：
- 設計符合工業級標準，可在高溫、高濕、振動等環境下穩定運行。
英文資料：
The Bently Nevada 3500/77M (176449-07) pressure monitor module is a high-performance monitoring device used for pressure signal monitoring and analysis in industrial applications, providing real-time protection and alarm functions. This module is part of the 3500 series and is widely used for status monitoring of critical equipment, especially in scenarios that require high reliability and precise pressure monitoring.
Product Overview
Attribute Details
Model 3500/77M
Order number 176449-07
Equipment type: Pressure monitor module
Bently Nevada 3500 Series
Main functions include real-time pressure monitoring, alarm, data analysis, and protection
Installation position: Installed in the 3500 frame
Key features
Multi channel monitoring:
Provide multiple input channels to monitor multiple pressure points simultaneously.
Each channel is independently configured to meet complex monitoring requirements.
High resolution signal processing:
Support real-time acquisition and high-precision processing of pressure signals.
Integrate digital signal processing (DSP) units to ensure data accuracy.
Alarm function:
Equipped with Alert and Danger alarm levels.
The alarm threshold can be freely set and adapted to various device operating conditions.
Modular design:
Support hot swappable design for easy maintenance or replacement without stopping system operation.
Seamlessly collaborate with other modules in the 3500 series to build a complete monitoring system.
Data recording and analysis:
Support real-time data output for easy analysis of device operation status.
Can record historical pressure data for trend analysis and fault diagnosis.
Adapt to harsh environments:
The design meets industrial standards and can operate stably in environments such as high temperature, high humidity, and vibration.
2.產 品 展 示
