ABB ACS600 3BHB011788R0001驅動器模塊PDF資料
1.產 品 資 料 介 紹：
中文資料：
ACS600 3BHB011788R0001 驅動器模塊 是 ABB 的一款工業變頻驅動器模塊，廣泛應用于復雜工業環境中的電機控制。這款模塊屬于 ACS600 系列，具有高性能和可靠性，能夠滿足嚴苛的自動化和能效需求。
產品特點
高性能控制
- 支持矢量控制和轉矩控制。
- 提供精確的速度和轉矩調節，適用于各種負載條件。
模塊化設計
- 方便集成和擴展，適應不同系統配置。
- 易于維護和更換，降低停機時間。
高效節能
- 內置節能算法，顯著降低能耗。
- 減少諧波干擾，支持更高的電能質量。
多種通信選項
- 支持常見工業通信協議（如 Profibus、Modbus）。
- 可輕松集成到現有的自動化系統中。
可靠性和耐用性
- 設計用于嚴苛的工業環境，能夠承受高溫、粉塵和振動。
- 內置過載、過熱和短路保護。
技術參數
| 參數 | 說明 |
|---|---|
| 型號 | ACS600 3BHB011788R0001 |
| 輸入電壓 | 380-500 V AC |
| 功率范圍 | 75 kW 至 500 kW |
| 頻率范圍 | 0-500 Hz |
| 控制方式 | 矢量控制、轉矩控制 |
| 效率 | >98% |
| 冷卻方式 | 風冷或液冷 |
| 保護功能 | 過載、短路、過壓、欠壓保護 |
| 環境溫度 | -10°C 至 +50°C |
| 通信接口 | RS485, Modbus, Profibus 等 |
英文資料：
The ACS600 3BHB011788R0001 driver module is an industrial variable frequency drive module from ABB, widely used for motor control in complex industrial environments. This module belongs to the ACS600 series and has high performance and reliability, capable of meeting demanding automation and energy efficiency requirements.
Product Features
High performance control
Support vector control and torque control.
Provide precise speed and torque regulation, suitable for various load conditions.
Modular design
Easy integration and expansion, adaptable to different system configurations.
Easy to maintain and replace, reducing downtime.
Efficient and energy-saving
Built in energy-saving algorithm significantly reduces energy consumption.
Reduce harmonic interference and support higher power quality.
Multiple communication options
Supports common industrial communication protocols such as Profibus and Modbus.
Can be easily integrated into existing automation systems.
Reliability and durability
Designed for harsh industrial environments, capable of withstanding high temperatures, dust, and vibration.
Built in overload, overheating, and short circuit protection.
technical parameter
Parameter Description
Model ACS600 3BHB011788R0001
Input voltage 380-500 V AC
Power range 75 kW to 500 kW
Frequency range 0-500 Hz
Control methods include vector control and torque control
Efficiency>98%
Cooling method: air cooling or liquid cooling
Protection function overload, short circuit, overvoltage, undervoltage protection
Environmental temperature -10 ° C to+50 ° C
Communication interface RS485, Modbus, Profibus, etc
2.產 品 展 示
