GE 239-RTD-AN 電機保護繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 239-RTD-AN 電機保護繼電器 是一種先進的電機保護設備，專門設計用于實時監測電機的運行狀態，并提供可靠的保護功能。以下是關于該繼電器的關鍵信息：
主要特點：
實時溫度監控：
- 支持 RTD（熱電阻）輸入，可監測電機繞組和軸承的溫度，防止過熱損壞。
- 多個 RTD 通道，用于同時監控不同部位的溫度。
多功能保護：
- 提供電機過熱保護、過載保護、欠載保護。
- 支持啟?？刂坪蛨?bào)警功能，可快速響應異常狀態。
先進的通信功能：
- 支持 Modbus 等工業通信協議，方便與 PLC 或 SCADA 系統集成。
- 可通過遠程監控和控制，實現智能化管理。
事件記錄：
- 內置事件記錄功能，能夠存儲故障和報警歷史，用于故障分析和維護優化。
用戶友好設計：
- 直觀的操作界面，易于安裝和設置。
- LED 指示燈和液晶顯示屏，提供實時狀態和報警信息。
技術規格：
| 項目 | 參數 |
|---|---|
| 電源電壓 | 120V AC 或 240V AC |
| 輸入類型 | RTD（銅、鉑或鎳熱電阻） |
| RTD 通道數量 | 6 或更多 |
| 通信接口 | RS-485，支持 Modbus |
| 工作溫度范圍 | -20°C 至 +70°C |
| 防護等級 | IP20（面板安裝時可達更高防護等級） |
| 安裝方式 | 面板安裝或 DIN 導軌安裝 |
英文資料：
The GE 239-RTD-AN motor protection relay is an advanced motor protection device designed specifically for real-time monitoring of the motor's operating status and providing reliable protection functions. The following is key information about the relay:
Main features:
Real time temperature monitoring:
Supports RTD (Thermistor) input, which can monitor the temperature of motor windings and bearings to prevent overheating damage.
Multiple RTD channels are used to simultaneously monitor the temperature of different parts.
Multi functional protection:
Provide motor overheating protection, overload protection, and underload protection.
Supports start stop control and alarm functions, and can quickly respond to abnormal states.
Advanced communication functions:
Supports industrial communication protocols such as Modbus for easy integration with PLC or SCADA systems.
Intelligent management can be achieved through remote monitoring and control.
Event record:
Built in event recording function, capable of storing fault and alarm history for fault analysis and maintenance optimization.
User friendly design:
Intuitive user interface, easy to install and set up.
LED indicator lights and LCD display screen provide real-time status and alarm information.
Technical specifications:
Project parameters
Power supply voltage 120V AC or 240V AC
Input type RTD (copper, platinum, or nickel thermistor)
RTD channel quantity 6 or more
Communication interface RS-485, supporting Modbus
Working temperature range -20 ° C to+70 ° C
Protection level IP20 (higher protection level can be achieved when installing the panel)
Installation method: panel installation or DIN rail installation
2.產 品 展 示
