METSO D201189 模擬模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
METSO D201189 模擬模塊 是 Metso 專為工業自動化系統設計的高性能模塊，用于處理模擬信號。該模塊在過程控制中扮演重要角色，廣泛應用于石油化工、能源、紙漿與造紙、以及金屬與礦業等行業，通過采集和傳輸高精度的模擬輸入/輸出信號，確保系統的可靠性和效率。
產品概述
- 產品型號：D201189
- 品牌：Metso
- 模塊類型：模擬輸入/輸出模塊
- 功能：采集模擬信號并與控制系統通信，實現過程參數的監測和調節。
技術規格
- 輸入信號：
- 支持標準工業模擬信號：0-20mA、4-20mA、0-10V 等。
- 輸入通道數量：4-8 個（具體配置視型號版本）。
- 輸出信號：
- 輸出范圍：4-20mA 或 0-10V（根據應用需求選擇）。
- 輸出通道數量：2-4 個（具體視模塊配置）。
- 分辨率：
- 支持高分辨率（12 位或 16 位 ADC），確保信號處理的精準性。
- 通信接口：
- 支持與 Metso 自動化系統和其他工業控制網絡（如 Modbus 或 Profibus）集成。
- 電源需求：
- 工作電壓：24V DC
- 功耗：低功耗設計，適合長時間運行。
- 環境適應性：
- 工作溫度范圍：-10°C 至 +55°C
- 儲存溫度范圍：-20°C 至 +70°C
- 防護等級：IP20（適用于控制柜內部安裝）。
產品特性
- 高精度信號處理：
- 使用先進的信號轉換和濾波技術，保證數據的準確性和穩定性。
- 模塊化設計：
- 易于擴展，可與其他 Metso 系列模塊組合使用，滿足復雜系統需求。
- 可靠性強：
- 設計符合工業環境的高可靠性標準，具備抗干擾能力。
- 靈活的配置選項：
- 支持多種輸入/輸出信號類型的組合配置，適應多樣化的工業應用。
- 快速故障診斷：
- 配備狀態指示燈和自診斷功能，便于運行監控和故障排查。
英文資料：
The METSO D201189 simulation module is a high-performance module designed by Metso specifically for industrial automation systems, used to process analog signals. This module plays an important role in process control and is widely used in industries such as petrochemicals, energy, pulp and paper, and metals and mining. By collecting and transmitting high-precision analog input/output signals, it ensures the reliability and efficiency of the system.
Product Overview
Product model: D201189
Brand: Metso
Module type: Analog input/output module
Function: Collect analog signals and communicate with the control system to monitor and adjust process parameters.
technical specifications
Input signal:
Support standard industrial analog signals: 0-20mA, 4-20mA, 0-10V, etc.
Number of input channels: 4-8 (specific configuration depends on model version).
Output signal:
Output range: 4-20mA or 0-10V (depending on application requirements).
Number of output channels: 2-4 (depending on module configuration).
resolving power:
Supports high-resolution (12 bit or 16 bit ADC) to ensure the accuracy of signal processing.
Communication interface:
Support integration with Metso automation systems and other industrial control networks such as Modbus or Profibus.
Power requirements:
Working voltage: 24V DC
Power consumption: Low power design, suitable for long-term operation.
Environmental adaptability:
Working temperature range:- 10 ° C to+55 ° C
Storage temperature range:- 20 ° C to+70 ° C
Protection level: IP20 (suitable for installation inside control cabinets).
Product Features
High precision signal processing:
Using advanced signal conversion and filtering techniques to ensure the accuracy and stability of data.
Modular design:
Easy to expand and can be combined with other Metso series modules to meet complex system requirements.
Strong reliability:
Designed to meet high reliability standards in industrial environments and possess anti-interference capabilities.
Flexible configuration options:
Support combination configuration of multiple input/output signal types to adapt to diverse industrial applications.
Quick fault diagnosis:
Equipped with status indicator lights and self diagnostic functions for easy operation monitoring and troubleshooting.
2.產 品 展 示
