ABB IPMON01 電源監視器模塊 T9831 擴展器接口 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB IPMON01 電源監視器模塊 是一款專門設計用于工業應用的電源監測設備，常用于監視和管理電源的狀態，確保系統的穩定運行。該模塊主要用于檢測供電參數（如電壓、電流等）并提供實時診斷信息，以實現高效的電源管理和保護。
產品特點
高精度監測
- 實時監測輸入電源的關鍵參數，包括電壓、電流、頻率和功率因數等。
多種報警功能
- 提供過壓、欠壓、過流等報警功能，及時提示異常狀態。
模塊化設計
- 緊湊型設計，易于集成到現有系統中。
通信支持
- 支持多種工業通信協議（如 Modbus 或以太網），便于數據傳輸和遠程監控。
高可靠性
- 設計符合工業環境的高抗干擾標準，適合惡劣條件下的長期運行。
技術參數
輸入電壓范圍：
支持多種工業標準電壓（如 100-240V AC 或 24V DC）。監測能力：
- 電壓：精確到 ±1%。
- 電流：多相或單相輸入監測。
- 頻率：通常支持 50/60 Hz。
輸出接口：
- 數字輸出：用于報警信號。
- 通信接口：RS485、Modbus RTU 等，支持與上位機或 PLC 的集成。
工作環境：
- 溫度：-10°C 至 60°C。
- 濕度：5% 至 95%（無凝結）。
安裝方式：
- 支持 DIN 導軌或面板安裝。
英文資料：
The ABB IPMON01 power monitor module is a power monitoring device specifically designed for industrial applications, commonly used to monitor and manage the status of power sources to ensure stable system operation. This module is mainly used to detect power supply parameters (such as voltage, current, etc.) and provide real-time diagnostic information to achieve efficient power management and protection.
Product Features
High precision monitoring
Real time monitoring of key parameters of the input power supply, including voltage, current, frequency, and power factor.
Multiple alarm functions
Provide alarm functions for overvoltage, undervoltage, overcurrent, etc., and promptly prompt abnormal states.
Modular design
Compact design, easy to integrate into existing systems.
Communication support
Supports multiple industrial communication protocols (such as Modbus or Ethernet) for easy data transmission and remote monitoring.
high reliability
Designed to meet high anti-interference standards in industrial environments, suitable for long-term operation under harsh conditions.
technical parameter
Input voltage range:
Supports multiple industrial standard voltages (such as 100-240V AC or 24V DC).
Monitoring capability:
Voltage: Accurate to ± 1%.
Current: Multiphase or single-phase input monitoring.
Frequency: Usually supports 50/60 Hz.
Output interface:
Digital output: used for alarm signals.
Communication interface: RS485, Modbus RTU, etc., supporting integration with upper computer or PLC.
Work environment:
Temperature:- 10 ° C to 60 ° C.
Humidity: 5% to 95% (no condensation).
Installation method:
Supports DIN rail or panel installation.
2.產 品 展 示
