TRICONEX 2301 控制器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX 2301 控制器模塊 是一種高可靠性、安全關鍵的控制器模塊，專為工業自動化和安全應用設計。它是 Triconex 系列可編程邏輯控制器（PLC）系統的一部分，廣泛應用于需要高可用性和容錯能力的場景。
產品概述
功能描述
- 三重模塊冗余 (TMR) 架構：內置三路獨立處理通道，確保系統運行的可靠性和安全性。
- 控制與監測功能：適用于安全儀表系統 (SIS)、緊急停車系統 (ESD) 和其他關鍵任務應用。
- 高可用性設計：即使在硬件或通信故障情況下，也能維持系統的連續運行。
應用場景
- 化工、石油和天然氣領域的過程控制和安全管理。
- 發電廠和電力輸送系統中的關鍵任務控制。
- 制藥、核工業等高安全性要求的行業。
技術規格
| 參數 | 規格說明 |
|---|---|
| 型號 | 2301 |
| 架構類型 | 三重模塊冗余 (TMR) |
| 輸入/輸出支持 | 支持?jǐn)?shù)字和模擬信號輸入/輸出 |
| 工作電壓 | 24V DC 或其他指定電源（具體需確認） |
| 工作溫度范圍 | -20°C 至 +70°C |
| 存儲溫度范圍 | -40°C 至 +85°C |
| 通信接口 | 支持多種工業通信協議（Modbus、TCP/IP 等） |
| 處理能力 | 高速實時處理能力 |
| 診斷功能 | 內置故障檢測與自診斷功能 |
| 兼容性 | 與其他 Triconex 系列模塊無縫集成 |
| 尺寸 | 模塊化設計，適用于標準機架安裝 |
英文資料：
The TRICONEX 2301 controller module is a highly reliable and safety critical controller module designed specifically for industrial automation and safety applications. It is part of the Triconex series of programmable logic controller (PLC) systems, widely used in scenarios that require high availability and fault tolerance.
Product Overview
Function Description
Triple Modular Redundancy (TMR) architecture: Built in three independent processing channels to ensure the reliability and safety of system operation.
Control and Monitoring Function: Suitable for Safety Instrumented Systems (SIS), Emergency Shutdown Systems (ESD), and other critical task applications.
High availability design: able to maintain continuous system operation even in the event of hardware or communication failures.
Application scenarios
Process control and safety management in the fields of chemical, petroleum, and natural gas.
Key task control in power plants and power transmission systems.
Industries with high safety requirements such as pharmaceuticals and nuclear industry.
technical specifications
Parameter specification description
Model 2301
Architecture Type Triple Modular Redundancy (TMR)
Input/output support supports both digital and analog signal input/output
Working voltage 24V DC or other specified power supply (specific needs to be confirmed)
Working temperature range -20 ° C to+70 ° C
Storage temperature range -40 ° C to+85 ° C
The communication interface supports multiple industrial communication protocols (Modbus, TCP/IP, etc.)
High speed real-time processing capability
Diagnostic function with built-in fault detection and self diagnosis capabilities
Compatibility seamlessly integrates with other Triconex series modules
Modular design for size, suitable for standard rack installation
