YOKOGAWA NFDV551-P10 數字輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
YOKOGAWA NFDV551-P10 數字輸出模塊 是 YOKOGAWA 自動化控制系統中的一款高性能數字輸出模塊，主要用于將控制系統的數字信號轉化為外部設備所需的輸出信號。它通常被應用于工業過程自動化、生產線控制、設備啟?？刂频阮I(lǐng)域，廣泛應用于需要數字信號控制的設備或系統中。
產品概述
功能描述
- 數字信號輸出：將控制系統中的數字信號轉化為外部設備（如執行器、閥門、開關等）的控制信號。
- 高兼容性：支持與 YOKOGAWA 控制系統及其他自動化控制設備無縫集成。
- 可靠性高：設計用于工業環境，確保穩定的信號傳輸和輸出控制。
應用場景
- 工業自動化生產線設備控制（如啟停、開關閥門等）。
- 化工、石油、天然氣等工業的自動化控制。
- 電力、制藥等行業中的儀器控制。
技術規格
| 參數 | 規格說明 |
|---|---|
| 型號 | NFDV551-P10 |
| 輸出類型 | 數字輸出（開關量信號） |
| 輸出通道數 | 通常為 8/16 通道（具體根據型號） |
| 輸出電壓 | 通常為 24V DC 或 48V DC，具體型號確認 |
| 輸出電流 | 通常支持最大 0.5A 到 1A（具體值需確認） |
| 隔離電壓 | 提供輸入/輸出的電氣隔離 |
| 輸出類型 | NPN 或 PNP 開關輸出 |
| 響應時間 | 快速響應時間，適用于快速切換應用 |
| 電源要求 | 24V DC |
| 工作溫度范圍 | -10°C 至 +60°C |
| 濕度范圍 | 5% 至 95% 無凝結 |
| 通信接口 | 與 YOKOGAWA 系統集成，支持主流通信協議 |
| 安裝方式 | 標準機架/導軌安裝 |
英文資料：
The YOKOGAWA NFDV551-P10 digital output module is a high-performance digital output module in the YOKOGAWA automation control system, mainly used to convert the digital signals of the control system into the output signals required by external devices. It is usually applied in industrial process automation, production line control, equipment start stop control and other fields, and is widely used in equipment or systems that require digital signal control.
Product Overview
Function Description
Digital signal output: Convert digital signals in the control system into control signals for external devices such as actuators, valves, switches, etc.
High compatibility: Supports seamless integration with YOKOGAWA control systems and other automation control devices.
High reliability: designed for industrial environments to ensure stable signal transmission and output control.
Application scenarios
Industrial automation production line equipment control (such as start stop, valve opening and closing, etc.).
Automation control in industries such as chemical, petroleum, and natural gas.
Instrument control in industries such as electricity and pharmaceuticals.
technical specifications
Parameter specification description
Model NFDV551-P10
Output type: Digital output (switch signal)
The number of output channels is usually 8/16 channels (depending on the model)
The output voltage is usually 24V DC or 48V DC, please confirm the specific model
The output current usually supports a maximum of 0.5A to 1A (specific value to be confirmed)
Isolation voltage provides electrical isolation for input/output
Output type NPN or PNP switch output
Fast response time, suitable for quickly switching applications
Power requirement 24V DC
Working temperature range -10 ° C to+60 ° C
Humidity range 5% to 95% without condensation
Communication interface integrated with YOKOGAWA system, supporting mainstream communication protocols
Installation method: Standard rack/rail installation
2.產 品 展 示
