SCHNEIDER ATV71HD22N4 變速驅動模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
SCHNEIDER ATV71HD22N4 變速驅動模塊 是施耐德電氣（Schneider Electric）推出的一款變頻驅動器，專為控制交流電動機的速度和轉矩而設計。它廣泛應用于各種工業自動化和機械設備控制中，能夠有效提升能源利用效率、優化設備運行，并支持多個控制功能。
產品概述
功能描述
- 變頻控制：ATV71HD22N4 變頻驅動器提供對交流電動機的精準調速控制，廣泛應用于泵、風機、輸送機、壓縮機等機械設備的驅動控制。
- 節能性能：通過調節電動機的運行速度，ATV71HD22N4 有效減少能源消耗，尤其適用于負載變化較大的場合，如風機和泵類設備。
- 多種控制方式：支持多種控制模式，包括轉矩控制、速度控制和閉環控制等，滿足不同應用需求。
應用領域
- 工業自動化：適用于各種工業設備，如水處理、HVAC（暖通空調）、包裝、紡織等領域的動力驅動系統。
- 電動機控制：為電動機提供高效、精確的速度和轉矩控制，確保設備平穩高效運行。
- 能源管理：在節能和能源優化方面，尤其是對電動機負載波動較大的場景，表現出色。
技術規格
| 參數 | 規格說明 |
|---|---|
| 型號 | ATV71HD22N4 |
| 電壓類型 | 交流電壓 380V - 480V |
| 功率范圍 | 11kW (15 HP) |
| 輸入電壓 | 380V - 480V, 3相交流電 |
| 輸出電壓 | 與輸入電壓一致 |
| 頻率范圍 | 0 - 590 Hz |
| 控制方式 | 矢量控制（V/f控制、閉環矢量控制、開環矢量控制） |
| 通訊協議 | Modbus RTU、Profibus DP、Ethernet/IP、CANopen等 |
| 環境溫度范圍 | -10°C 至 +50°C |
| 相數 | 三相電源 |
| 顯示界面 | LED 顯示面板，支持鍵盤輸入 |
| 過載能力 | 150% 額定電流，1分鐘 |
| 尺寸 | 約 380 x 260 x 240 mm (具體尺寸根據具體型號略有不同) |
| 保護功能 | 過載保護、過電流保護、過熱保護、防塵、防水等 |
英文資料：
The SCHNEIDER ATV71HD22N4 variable speed drive module is a variable frequency drive developed by Schneider Electric, specifically designed to control the speed and torque of AC motors. It is widely used in various industrial automation and mechanical equipment control, which can effectively improve energy utilization efficiency, optimize equipment operation, and support multiple control functions.
Product Overview
Function Description
Variable frequency control: The ATV71HD22N4 variable frequency drive provides precise speed control for AC motors and is widely used in the drive control of mechanical equipment such as pumps, fans, conveyors, compressors, etc.
Energy saving performance: By adjusting the operating speed of the motor, ATV71HD22N4 effectively reduces energy consumption, especially suitable for situations with large load changes, such as fans and pumps.
Multiple control modes: Supports multiple control modes, including torque control, speed control, and closed-loop control, to meet different application requirements.
application area
Industrial automation: Suitable for power drive systems in various industrial equipment fields such as water treatment, HVAC (Heating, Ventilation and Air Conditioning), packaging, textiles, etc.
Electric motor control: provides efficient and precise speed and torque control for electric motors, ensuring smooth and efficient operation of equipment.
Energy management: Excellent performance in energy conservation and optimization, especially in scenarios with large fluctuations in motor load.
technical specifications
Parameter specification description
Model ATV71HD22N4
Voltage type: AC voltage 380V -480V
Power range 11kW (15 HP)
Input voltage 380V -480V, 3-phase AC current
The output voltage is consistent with the input voltage
Frequency range 0-590 Hz
Control method vector control (V/f control, closed-loop vector control, open-loop vector control)
Communication protocols include Modbus RTU, Profibus DP, Ethernet/IP, CANopen, etc
Environmental temperature range -10 ° C to+50 ° C
Phase number three-phase power supply
Display interface LED display panel, supporting keyboard input
Overload capacity 150% rated current, 1 minute
The size is approximately 380 x 260 x 240 mm (the specific size may vary slightly depending on the specific model)
Protection functions include overload protection, overcurrent protection, overheating protection, dust prevention, waterproofing, etc
2.產 品 展 示
