如今以太網交換機已廣泛應用于通信行業中，在SOHO型企業中一個8端口的普通以太網交換機也許就能滿足需求，而在數據中心機房中則需要24端口或更多端口以及更高性能的以太網交換機。看似平常的以太網交換機卻蘊含著五大突出特性，下面將一一探討。
更快的速度
最初的以太網規范描述了10Mbps標準，經過多年發展速度已從百兆位上升到了千兆位，如今100Gbps以太網規范已出臺。更高速以太網標準的出臺也促使快速以太網交換機得到不同程度發展，快速以太網交換機支持全線速無阻塞交換以及端口自動翻轉功能，采用全雙工工作模式避免了沖突檢測，提高了數據轉發速度。
支持VLAN
以太網基本架構允許個人電腦、服務器和存儲設備都接入到同一臺以太網交換機上，這樣做的同時產生了一些問題，比如不同業務流量的廣播信息可能會泛洪到所有設備上，在產生額外流量的同時對于網絡管理來說也是不安全的。而以太網交換機支持虛擬局域網(VLAN)，可以在同一臺交換機上創建隸屬于不同業務需求的子網，不同VLAN上的設備盡管連接到相同的交換機上，但其MAC地址廣播卻被隔離在相同VLAN中，提高了管理性能，也增強了安全性。
以太網供電(PoE)
PoE將直流電源傳送到連接在以太網交換機上的設備，這樣可以大大簡化設備部署。比如無線接入點、網絡攝像機和IP電話等通過以太網交換機傳送過來的直流電便可驅動設備工作，不再需要獨立的電源模塊，使其可以比較方便的在任何有網絡連接的地方進行工作。
服務質量(QoS)
以太網交換機支持QoS功能，允許網絡管理員指定不同數據流量傳輸時的優先級別。這樣就可以確保用戶在玩游戲或觀看視頻時沒有耗盡所有的帶寬，當其他用戶使用網絡電話時，通過交換機上的QoS機制保障通話質量。這為網絡管理帶來了便捷性，可以針對不同企業不同的業務需求降低非關鍵業務的優先級，從而使關鍵業務流量快速順利的進行傳輸。large, the wire coming out is too loose, and the loose wire will be broken like the stranded wire if it is not immediately stowed. Therefore, the normal startup and pulling out of qualified wire can be realized only if the slip is guaranteed to be within a certain deviation. The deviation between the actual value of the slip and the set slip should be controlled between 0.1 and -0.1m/s. The wire drawing machine operates at a constant speed after being input by AI2, and PLC controls the take-up frequency f = F1 F2 by detecting the calculated slip.
4、 Advantages of h2u series PLC in wire drawing machine
a) Fast instruction execution time
In 3335 steps of the whole program, a large number of complex instructions are used internally, such as PID, SPD, floating-point calculation, floating-point comparison, etc., and the monitored scanning time is only 6ms.
b) Fast communication speed and simple programming
The highest baud rate of Modbus communication is 38400bps, which makes the rapid adjustment of PID possible, while most brand minicomputers only reach 19200bps. The communication programming is simple, which can be realized with one RS command, and the other programs are completed by the system program. The communication control can be easi
