Following this message there is a delay to allow you an
opportunity to abort the Autoboot process if you wish. To
gain control without Autoboot, you can press the BREAK key
or the software ABORT or RESET switches.
5. Then the actual I/O begins: the program pointed to within
the volume ID of the media specified is loaded into RAM and
control passed to it.
Autoboot is controlled by parameters contained in the ENV
command. These parameters allow the selection of specific boot
devices and files, and allow programming of the Boot delay. Refer
to the ENV command in Appendix A for more details.
ROMboot
There are two spare EPROM sockets, XU3 and XU4, available to
carry user-programmed EPROMs. Therefore, you do not have to
reprogram the 187Bug EPROMs in order to implement the
ROMboot feature.
One use of ROMboot might be resetting SYSFAIL* on an
unintelligent controller module. The NORB command disables the
function.
ROMboot Sequence
1. ROMboot is configured/enabled and executed at powerup
(optionally also at reset) in one of two ways:
a. By the Environment (ENV) command (refer to
Appendix A)
b. By the RB command assuming there is valid code in the
EPROMs (or optionally elsewhere on the module or
VMEbus) to support it.
2. If ROMboot code is installed, a user-written routine is given
control (if the routine meets the format requirements). For a user's ROMboot module to gain control through the
ROMboot linkage, four requirements must be met: Power must have just been
applied.
Change this to respond to any reset.
Your routine must be located
within the MVME187 ROM
memory map.
Change this to any other portion of the onboard
memory, or even offboard VMEbus memory.
The ASCII string “BOOT” must be located within the specified memory range.
Your routine must pass a checksum test, which ensures that this routine was really
intended to receive control at powerupFor complete details on how to use ROMboot, refer to the
Debugging Package for Motorola 88K RISC CPUs User's Manual.
