If a contiguous block of
memory, 64KB in size, is not found in
the range specified by Memory Search
Starting Address and Memory Search
Ending Address parameters, then the
bug will place its work page in the
onboard static RAM on the
MVME187. Default Memory Search
Ending Address is the calculated size
of local memory. There will be no delay before the Bug
begins its search for a work page.
The following VMEbus disk/tape controller modules are
supported by the 187Bug. The default address for each controller
type is First Address and the controller can be addressed by First
CLUN during commands BH, BO, or IOP, or during TRAP #496
calls .DSKRD or .DSKWR.
Note that if another controller of the same type is used, the second
one must have its address changed by its onboard jumpers and/or
switches, so that it matches Second Address and can be called up by
Second CLUN.The VMEbus network controller modules supported by
MVME187Bug are shown in Table C-1. The default address for each
type and position is shown to indicate where the controller must
reside to be supported by MVME187Bug.
The CLUNs and DLUNs are used in conjunction with the following
debugger commands and debugger system calls:? Try these simple troubleshooting steps before calling for help
or sending your CPU board back for repair.
? Some of the procedures will return the board to the factory
debugger environment. (The board was tested under these
conditions before it left the factory.)
? Selftest may not run in all user-customized environments.1. Make sure the system is plugged in.
2. Check that the board is securely installed in its
backplane or chassis.
3. Check that all necessary cables are connected to
the board, per this manual.
4. Check for compliance with System
Considerations, in Chapter 3.
5. Review the Installation and Startup procedures,
in Chapter 3. The step-by-step powerup routine
for your board is on page 3-17. Try it.
B. If the LEDs
are lit, the board
may be in the
wrong slot.
1. The CPU board should be in the first (leftmost)
slot if it is to be the system controller.
2. The “system controller” function requires that
header J2 be set properly. See Chapter 3.
