以下各節討論了MVME197LE在VME中的安裝機箱和系統注意事項。確保引導ROM設備安裝。確保根據需要配置所有交換機。現在MVME197LE模塊已準備好進行安裝，請按照跟隨：
a、 關閉所有設備電源，斷開電源電纜與電源。b、 按照設備用戶手冊中的說明卸下機箱蓋。
c、 從正面和側面的相應卡槽中卸下填充板機箱后部（如果機箱具有后卡固定框架）。
DS200TCEAG1ACB通用卡件MVME197LE模塊需要P1和P2供電。它可以安裝在任何雙高未使用的卡槽（如果未配置為系統）控制器。如果MVME197LE配置為系統控制器，則必須安裝在最左側的卡插槽（插槽1）中才能正確啟動總線授予雛菊鏈，并使IACK雛菊鏈驅動程序正常運行。MVME197LE將安裝在機箱前部MVME712X過渡板具有雙寬前面板將安裝在機箱后部。
d、 小心地將MVME197LE模塊滑入卡槽。確保模塊正確安裝在背板上的P1和P2連接器中。
不要損壞或彎曲連接器針腳。將模塊固定在機箱中提供螺釘，與橫向安裝件接觸良好減少RFI排放的軌道。
e、 從機箱的收割臺上拆下IACK和BG跳線安裝MVME197LE的卡槽的背板。
f、 將P2適配器板和指定電纜連接到MVME197LE在MVME197LE插槽背板上的P2處，匹配（可選）EIA-232-D串行端口、并行端口處的終端或其他外圍設備，SCSI端口和LAN以太網端口。請參閱相關手冊中列出的手冊有關安裝P2適配器板的信息，請參閱文檔部分和MVME712X轉換模塊。（MVME197LE、MVME197DP和MVME197SP Single中提供了一些連接圖板機程序員參考指南）。有些電纜沒有配備MVME712X模塊，因此，制造或由用戶提供。（摩托羅拉建議所有用戶使用屏蔽電纜與外圍設備的連接，以盡量減少輻射）。連接電纜的外圍設備。
g、 在系統中安裝任何其他必需的VMEmodules。h、 更換機箱蓋。
i、 將電源電纜連接到交流電源，然后轉動設備打開電源。
The following sections discuss installation of the MVME197LE into a VME
chassis, and system considerations. Ensure that BOOT ROM device is
installed. Ensure that all switches are configured as desired.Now that the MVME197LE module is ready for installation, proceed as
follows:
a. Turn all equipment power OFF and disconnect the power cable from the
power source.b. Remove the chassis cover as instructed in the equipment user’s manual.
c. Remove the filler panel(s) from the appropriate card slot(s) at the front and
rear of the chassis (if the chassis has a rear card cage). The MVME197LE
module requires power from both P1 and P2. It may be installed in any
double-height unused card slot, if it is not configured as the system
controller. If the MVME197LE is configured as the system controller, it
must be installed in the left-most card slot (slot 1) to correctly initiate the
bus-grant daisy-chain and to have proper operation of the IACK-daisychain driver. The MVME197LE is to be installed in the front of the chassis
and the MVME712X transition board which has a double-wide front panel
is to be installed in the rear of the chassis.
d. Carefully slide the MVME197LE module into the card slot. Be sure the
module is seated properly into the P1 and P2 connectors on the backplane.
Do not damage or bend connector pins. Fasten the module in the chassis
with screws provided, making good contact with the transverse mounting
rails to minimize RFI emissions.
e. Remove the IACK and BG jumpers from the header on the chassis
backplane for the card slot in which the MVME197LE is installed.
f. Connect the P2 Adapter Board and specified cable(s) to the MVME197LE
at P2 on the backplane at the MVME197LE slot, to mate with (optional)
terminals or other peripherals at the EIA-232-D serial ports, parallel port,
SCSI ports, and LAN Ethernet port. Refer to the manuals listed in Related
Documentation section for information on installing the P2 Adapter Board
and the MVME712X transition module. (Some connection diagrams are provided in the MVME197LE, MVME197DP, and MVME197SP Single
Board Computers Programmer’s Reference Guide). Some cable(s) are not
provided with the MVME712X module and therefore, are made or
provided by the user. (Motorola recommends using shielded cables for all
connections to peripherals to minimize radiation). Connect the
peripherals to the cable(s).
g. Install any other required VMEmodules in the system.
h. Replace the chassis cover.
i. Connect the power cable to the ac power source and turn the equipment
power ON.
