IS230TVBAH2A燃機備件,GE使用配置教程
磁盤輸入/輸出錯誤代碼如果嘗試的磁盤操作不成功，197Bug將返回錯誤代碼。
網絡輸入/輸出支持網絡引導固件提供通過以下方式引導CPU的能力：使用網絡（本地以太網接口）作為引導的ROM調試器裝置引導過程分兩個不同的階段執行。
? 第一階段允許無盤遠程節點發現其網絡標識和要引導的文件的名稱。
? 第二階段是無盤遠程節點跨網絡進入其內存。各種模塊（功能）和這些模塊的依賴關系以下介紹了支持整體網絡引導功能的段落。
IS230TVBAH2A燃機備件物理層管理器以太網驅動程序該驅動程序管理/包圍以太網控制器芯片或板。管理的范圍是接收數據包，傳輸數據包數據包、接收緩沖區刷新和接口初始化。該模塊確保以太網數據包的打包和解包在啟動PROM中正確完成。UDP/IP協議模塊互聯網協議（IP）設計用于分組交換計算機通信網絡?；ヂ?lián)網協議用于傳輸稱為數據報的數據塊（因此用戶數據報協議（UDP），從源到目標，其中源和目的地是由固定長度地址標識的主機。UDP/IP協議是TFTP和BOOTP協議、TFTP所必需的BOOTP需要UDP/IP連接。RARP/ARP協議模塊反向地址解析協議（RARP）基本上由一個無身份節點在以太網上廣播“whoami”數據包，以及等待答案。RARP服務器向以太網回復數據包填充目標的Internet地址并將其發送。
地址解析協議（ARP）基本上提供了一種將協議地址（例如IP地址）轉換為局域網地址（例如以太網地址）。RARP協議模塊支持不支持BOOTP協議的系統（下一段）。BOOTP協議模塊引導協議（BOOTP）基本上允許無盤客戶機發現其自己的IP地址、服務器主機的地址和文件名被載入內存并執行。TFTP協議模塊普通文件傳輸協議（TFTP）是一種傳輸文件的簡單協議。
它是在互聯網用戶數據報協議（UDP或數據報），因此它可以用于在不同計算機上的計算機之間移動文件實現UDP的網絡。它唯一能做的就是讀寫文件從/到遠程服務器。
Disk I/O Error Codes
197Bug returns an error code if an attempted disk operation is unsuccessful.
Network I/O Support
The Network Boot Firmware provides the capability to boot the CPU through
the ROM debugger using a network (local Ethernet interface) as the boot
device.
The booting process is executed in two distinct phases.
? The first phase allows the diskless remote node to discover its network
identity and the name of the file to be booted.
? The second phase has the diskless remote node reading the boot file across
the network into its memory.
The various modules (capabilities) and the dependencies of these modules
that support the overall network boot function are described in the following
paragraphs.Physical Layer Manager Ethernet Driver
This driver manages/surrounds the Ethernet controller chip or board.
Management is in the scope of the reception of packets, the transmission of
packets, receive buffer flushing, and interface initialization.
This module ensures that the packaging and unpackaging of Ethernet packets
is done correctly in the Boot PROM.
UDP/IP Protocol Modules
The Internet Protocol (IP) is designed for use in interconnected systems of
packet-switched computer communication networks. The Internet protocol
provides for transmitting of blocks of data called datagrams (hence User
Datagram Protocol, or UDP) from sources to destinations, where sources and
destinations are hosts identified by fixed length addresses.
The UDP/IP protocols are necessary for the TFTP and BOOTP protocols, TFTP
and BOOTP require a UDP/IP connection.
RARP/ARP Protocol Modules
The Reverse Address Resolution Protocol (RARP) basically consists of an
identity-less node broadcasting a “whoami” packet onto the Ethernet, and
waiting for an answer. The RARP server fills an Ethernet reply packet up with
the target's Internet Address and sends it.
The Address Resolution Protocol (ARP) basically provides a method of
converting protocol addresses (e.g., IP addresses) to local area network
addresses (e.g., Ethernet addresses). The RARP protocol module supports
systems which do not support the BOOTP protocol (next paragraph).
BOOTP Protocol Module
The Bootstrap Protocol (BOOTP) basically allows a diskless client machine to
discover its own IP address, the address of a server host, and the name of a file
to be loaded into memory and executed.
TFTP Protocol Module
The Trivial File Transfer Protocol (TFTP) is a simple protocol to transfer files.
It is implemented on top of the Internet User Datagram Protocol (UDP or
Datagram) so it may be used to move files between machines on different
networks implementing UDP. The only thing it can do is read and write files
from/to a remote server.
