After board-selection has occurred, three groups of VMEbus signals
control communications with the board. They are as follows:
a. Data Bus lines D00 to D15
b. Address lines A01, A02, A03, A04, A05, A06, A07
c. Bus Control Signals:
(1) WRITE
(2) DS0,* DS1*
(3) SYS CLK
(4) SYS RESET*
Data bus lines are bi-directional and move data to and from the board
through a 16-bit data transceiver in response to control signals from the control
decoder. The data transceiver serves as a buffer for the internal data bus which
interconnects all data devices on the board.
Address lines A01 through A07 map the 128 communication registers
onto a 256-byte range within the VME address space (Section 4). The control
signals determine whether data is to be moved to the VMIVME-3112 (write) or from
the VMIVME-3112 (read), provide the necessary data strobes (DS0, DS1), and
supply a 16 MHz clock (SYS CLK) for use by on-board timers. A SYS RESET input
resets all timers and flags.
Static controls are latched into the Control Register and are used
primarily to establish the operational mode of the board. Status flags, necessary
for monitoring and controlling the analog input multiplexer and the ADC are read
through the Status Register. The control and status registers are referred to
collectively as the Control and Status Register (CSR), since they are at the same
address. The WRITE signal determines which one is accessed. Most of the control
register outputs can be monitored directly through the Status Register.
3.4 ANALOG-TO-DIGITAL (ADC) CONTROL AND TIMING
Control commands and status flags associated with controlling the ADC
are illustrated in Figure 3.3-1, and are described in Section 4 and the following sections.
There are three mode control bits in the CSR. The programming of these
control bits (Mode 0H through Mode 2H) determine which one of five ADC
operating modes the board is to operate in. The five ADC operating modes and the
Control Register mode control bits areThe ADC operating modes basically determine if the on-board ADC and
channel selection are controlled externally by a CPU board or by the on-board
channel sequencer. They also determine whether an interrupt will be generated
when the conversion(s) are complete. The five ADC operating modes will be
described from a programming viewpoint in Section 4.
The AUTO SCANNING MODE (Mode 0), RANDOM POLL MODES, and
SCANNING POLL MODE will be discussed here to reveal the ADC controls and
timing intervals. The other two modes use interrupts instead of polling to determine
when a conversion or a series of conversions are completed.
