Features
High Performance Parallel Programmer Interface
Bus Expansion Interface
Supports up to 7 Expansion racks
Three LED indicators provide module, programmer port, and expansion port status
No DIP switches to set, easy software configuration into PLC system
Functions
The Bus Transmitter Module (BTM) permits expansion from the main CPU rack when more modules are
required in a system than can be contained in the
CPU rack. The BTM allows expansion from the CPU
rack to a maximum of 7 additional IC697 PLC racks. It
also provides a high performance parallel interface to
the programming device.
The module occupies a single slot and has two connectors. The top one is for attachment to the programming device. The bottom one is for a daisychained arrangement through Bus Receiver Modules
to expansion racks.
Three green LEDs provide status indication of each
port and module status.
The BTM must be configured into the IC697 PLC system using the MS-DOS or Windows programming
software configuration function.Installation
Installation should not be attempted without referring to the applicable Programmer Controller Installation Manual (See reference 3).
Make sure rack power is off.
Install in any slot (except slot 1) in the main CPU
rack.
Turn on power.
Note
BTM Version IC697BEM713A must be
installed to the right of any IC697 interrupt
source modules (GBC, PCM, Integral Inputs).
BTM Version IC697BEM713B and later
versions can be installed as shown in Figure 1.
Module Mechanical Keying
This module includes a mechanical key that prevents
inadvertent substitution of one module type for
another in a given slot. The key fits a uniquely
shaped area on the board below the connector. The
key is included with each module.
