新風光通過對逆變器多電平電路拓?fù)浣Y(jié)構技術、電壓型逆變器的電流源控制技術、單元并聯技術、并網技術等關鍵技術進行攻關，實現了突破。在國內首創并成功運行在軌道交通行業，填補了國內空白。通過該項目關鍵技術開發與應用，滿足了城市軌道交通行業低碳綠色環保節能的需求，推動國產軌道交通裝備的提質增效。
3 新風光FDBL-JC-650/1500V型再生制動能量吸收逆變裝置介紹
該逆變裝置具有動態響應快，并網電流諧波小，回饋能量效率高，可靠性高。產品經鐵道部質量監督檢驗中心檢驗，各項技術指標均達到設計要求。該設備被列入科技部2014年度國家火炬計劃項目，山東省重點領域首臺套裝備名單。
3.1新風光FDBL-JC-650/1500V型再生制動能量吸收逆變裝置主要技術參數
新風光FDBL-JC-650/1500V型再生制動能量吸收逆變裝置主要技術參數如下：
(1)功率：峰值功率650kW，持續時間20s，周期120s
(2)工作制：間歇工作制
(3)啟動電壓值：1530V~1980V連續平滑可調
(4)輸出電壓：AC1000V 三相三線制
(5)頻率：跟蹤交流側電網頻率
(6)額定工況下輸出功率因數：＞0.98
(7)額定工況下整套設備效率：＞97%
(8)額定工況下電流諧波含量：≤3％
(9)額定工況下電壓諧波含量：≤3％
（10）裝置響應時間：≤200ms
3.2主要工作原理
