PQMII-T20電氣工控模塊RAC05-SK/480 系列的 5W AC/DC 轉換器符合 OVC III,并且提供85VAC 到 528VAC 的超寬電壓輸入范圍。在單相系統中它們?yōu)橄嗟街行跃€提供100 VAC 至 277 VAC電壓,或在沒有中性線的三相系統中為相到相提供208/480VAC電壓。5V、12V 或 15V 輸出的絕緣強度規定在每分鐘4kVAC。RAC05-SK/480 模塊的工作溫度范圍為 –40°C 至 +80°C,這使得該設備成為惡劣環境中戶外充電站的理想選擇。
PQMII-T20電氣工控模塊如果需要更高的功率,我們建議使用 RAC10-SK/277 系列模塊作為輔助電源。該系列的輸入電壓范圍在 85 VAC 和 305 VAC 之間,為單相連接提供 100VAC 至 277VAC 的電壓。RAC10-SK/277 和 RAC05-SK/480一樣符合 OVC-III。這些獲得工業和家用(IEC 60335) 認證的低成本模塊提供 3.3VDC 至 24VDC 以及 ±12VDC 或 ±15VDC 的輸出電壓,因此幾乎涵蓋所有應用。它們主要的優勢是可輸出 140% 峰值功率,這使 RAC10-SK/277 模塊成為高啟動電流的電池充電和監控系統的理想選擇。
這兩個系列無需外部濾波器即可滿足 EMC Class B的要求,提供低待機功耗,尺寸僅 2” x 1” 適合PCB安裝。
另一個與 EV 充電站相關的產品系列是隔離式 DC/DC 轉換器,特別是具有 5kVAC 增強隔離和 1kVAC,rms 工作電壓的 RxxCTxx 系列模塊。這些薄型轉換器采用專為焊接設計的 SOIC 封裝。它們支持用戶自定義、可調節和防短路的 3.3 VDC 或 5 VDC 單路輸出電壓。模塊提供 500mW 使它們特別適合傳感器和通信應用。在 400mW 負載和 5VDC 輸入電壓下,工作溫度范圍為 –40°C 至 +110°C。
RKE/H 系列的設計較為傳統(SIP7 和 THT),這些低成本的模塊提供 1W 以上的輸出功率,通常使用在成本敏感的應用上。模塊的輸入電壓為 5V、12V 或 24VDC,而5VDC輸出提供 4kVDC 的隔離電壓。RKE/H 是一款用在絕緣接口、控制器和傳感器設備,監控充電電流和電池電壓的強大電源。RKE 轉換器的效率高達 81%。除非PCB 已經過屏蔽處理,否則安裝時可能需要結合使用小型 EMC 濾波器 (LC)。
兩種 DC/DC 轉換器類型都非常適合電池充電器、公共 EV 充電站、私人 EV 充電墻盒以及許多需要超高電位隔離的工業應用。
還有專門用于 48V 電池的EV充電站。這些充電站通常是給小型EV使用,包括自動導引車、物料運輸手推車、高爾夫球車等,也可當作插電式輕混合動力EV的充電點。
