安全信息
1類激光收發器
單模接口模塊使用1類激光收發器。
安裝或操作這些模塊前，請閱讀以下安全信息。
1類激光收發器使用光學反饋回路來維持1類操作限制。該控制回路消除了
需要進行維護檢查或調整。輸出為出廠設置，不允許用戶進行任何調整。
1類激光器收發器符合以下安全標準：
?21 CFR 1040.10和1040.11美國衛生與公眾服務部（FDA）。
?IEC出版物825（國際電工委員會）。
?CENELEC EN 60825（歐洲電工標準化委員會）。
當在其性能限制范圍內運行時，激光收發器輸出滿足所有設備的1級可訪問發射限制
三個標準。1級激光輻射水平不被視為危險。
當連接器就位時，所有激光輻射都留在光纖內。輻射功率的最大輸出量
光纖（在正常條件下）為-12.6 dBm或55 x 10-6瓦。
從收發器上卸下光學連接器可使激光輻射直接從光學端口發射。最大
來自光學端口的輻射（在最壞情況下）為0.8 W cm-2或8 x 103 W m2 sr-1。
請勿使用光學儀器查看激光輸出。使用光學儀器查看激光輸出可提高視力
危險查看輸出光端口時，必須斷開網絡適配器的電源。
Safety Information
Class 1 Laser Transceivers
The single mode interface modules use Class 1 laser transceivers.
Read the following safety information before installing or operating these modules.
The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the
need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser
transceivers comply with the following safety standards:
? 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA).
? IEC Publication 825 (International Electrotechnical Commission).
? CENELEC EN 60825 (European Committee for Electrotechnical Standardization).
When operating within their performance limitations, laser transceiver output meets the Class 1 accessible emission limit of all
three standards. Class 1 levels of laser radiation are not considered hazardous.
When the connector is in place, all laser radiation remains within the fiber. The maximum amount of radiant power exiting the
fiber (under normal conditions) is ‐12.6 dBm or 55 x 10‐6 watts.
Removing the optical connector from the transceiver allows laser radiation to emit directly from the optical port. The maximum
radiance from the optical port (under worst case conditions) is 0.8 W cm‐2 or 8 x 103 W m2 sr‐1.
Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye
hazard. When viewing the output optical port, power must be removed from the network adapter.
