The Phase Correction Procedure requires that the prime mover be shut down
many times to disconnect the current transformers. For convenience, a
temporary method of connecting the current transformers shown in Figure 3-2 is
recommended. Connecting a 1 ?, 5 W burden resistor across each current
transformer allows the current transformers to be disconnected from the terminal
strip with the prime mover running, after removing all load.
HIGH VOLTAGE—The current transformers can develop dangerously
high voltages. Do not disconnect a current transformer while the
prime mover is running unless temporary 1 ?, 5 W resistors are
Installed as shown In Figure 3-2, and all load is removed.
Figure 3-2. Temporary Wiring for Transformer Phase Correction
If the temporary burden resistors described above and shown in Figure 3-2 are
not used, the prime mover MUST be shut down in addition to removing the load
in the following procedure.
Measure the load-signal voltage in this procedure by connecting a voltmeter
across the Load Signal terminals 11 (–) and 13 (+).
1. Shut down the prime mover.
2. Label each CT wire with the phase and polarity that you think it should be.
Even though this identification may prove to be incorrect, this step is
necessary so that the individual wires may be identified during the
description of the procedure.
3. Disconnect the phase B CT wires from terminals 6 and 7. Connect these
two wires together using a small screw and nut, and tape the connection.
4. Disconnect the phase C CT wires from terminals 8 and 9. Connect and tape
these two wires together as in step 3.
5. Connect the two wires from the phase A CT to the phase A input terminals 4
and 5.
6. Start the prime mover, apply full load, and measure the load signal voltage.
Start a list and record this voltage. 7. Unload the system and reverse the phase A CT wires on terminals 4 and
5. *
8. Apply full load, measure the load signal, and record this voltage.
9. Unload the system, remove the phase A CT wires from terminals 4 and 5,
and connect them to phase B input terminals 6 and 7. *
10. Apply full load, measure the load signal, and record this voltage.
11. Unload the system and reverse the phase A CT wires on terminals 6 and
7. *
12. Apply full load, measure the load signal, and record this voltage.
13. Unload the system, remove the phase A CT wires from terminals 6 and 7,
and connect them to phase C input terminals 8 and 9. *
14. Apply full load, measure the load signal, and record this voltage.
15. Unload the system and reverse the phase A CT wires on terminals 8 and
9. *
16. Apply full load, measure the load signal, and record this voltage.
17. Unload the system and compare the six voltage readings. *
