Check actuator linkage to fuel controlling
mechanism for any lost motion, binding, or
excessive loading. Verify a steady fuel
pressure of proper value.
Check actuator per appropriate actuator
manual.
Prime mover not operating
properly.
Prime mover may be causing speed
variations. Control engine manually to
determine if instability is in prime mover or
governor control. Verify proper adjustment
of fuel control linkage.
Input voltage low. Check supply voltage, It should be at least
20 Vdc on low voltage controls and 90 Vdc
or 88 Vac on high voltage controls.
Speed-setting
control does not
regulate speed.
Faulty RATED SPEED or Speed
Trim potentiometer.
Check by replacing Speed Trim with jumper
and setting speed with main speed
potentiometer. Prime mover not receiving fuel as
called for by the governor.
If voltage to actuator is maximum (minimum
for reverse-acting), visually determine if
actuator shaft is at maximum position. If it is
not, an actuator problem is indicated, or the
linkage or fuel system is restricted. Unequal speed settings. Be sure that speed settings of all units at no
load are identical.
Unequal load-gain voltages. With the prime mover operating in single
unit configuration, LOAD GAIN must be set
at 6.0 Vdc. See “Load Gain Adjustment” in
Chapter 3.
Circuit breaker auxiliary contact
or droop contact is open.
Check auxiliary circuit breaker and droop
contacts. Check for 18 to 40 Vdc from
terminal 14 to 15 on low voltage controls.
NOTE
High voltage controls can only be measured
from terminal 14 to 18 if the close to
override failed speed signal contact is not
closed.
Improper load-sensing phasing. Perform phasing procedure in Chapter 3.
Circulating currents between
generators.
Refer to appropriate voltage regulator
manual.
Prime mover does
not maintain
constant speed
(isochronous).
Actuator. If actuator has a ballhead backup, verify
that its hydraulic governor section, speed
setting, and speed droop adjustments are
properly set (see the applicable governor
manual).
Prime mover. If droop occurs near the full-load point only,
it is possible the prime mover is not
producing the power called for by the fuel
control, or is being overloaded. Either is
indicated if the fuel control is at maximum
position.
