Timing in the case of breaker failure:
(1) A fault has occurred and been detected by a protective device.
(2) A tripping command is transmitted to the circuit-breaker after the unit protection operating time which also starts the
BFP. The tripping command can be either single (Start Lx) or
three-phase (Start L1L2L3). The redundant signals are also
activated at the same time.
(3) The circuit-breaker ruptures the fault current.
(4) After the reset delay tReset plus a safety margin tMargin , the
BFP either detects that the fault current has been interrupted and the protection function resets, or the fault current continues to flow and a second attempt is made by the
BFP to trip the circuit-breaker.
(5) The second attempt to trip the circuit-breaker is successful
and the fault current is interrupted.After a further reset delay tReset plus a safety margin tMargin ,
the BFP either detects that the fault current has been interrupted and the protection function resets, or the fault current continues to flow and the BFP initiates backup tripping.
If the BFP is only required to carry out a single breaker failure
step, timer t1 can be disabled (see ‘t1 active’). The response of
the BFP corresponds once again to Fig. 3.5.33.1, but with timer
t1 set to zero.
Timing in the case of an unconditional trip:
(1) A fault has occurred and been detected by a protective device.
(2) A signal at input ‘Ext Start’ starts the UT function.
(3) The circuit-breaker ruptures the fault current.
(4) If after the reset delay tReset plus a safety margin tMargin , the
CB auxiliary contact “CB On” still signals to the UT that the
CB is closed, a second attempt is made by the UT function
to trip the circuit-breaker.
(5) The second attempt to trip the circuit-breaker is successful
and the fault current is interrupted.
(6) If after a further reset delay tReset plus a safety margin tMargin
the CB auxiliary contact “CB On” still signals to the UT that
the CB is closed, backup tripping is initiated by the UT
function.Timing diagram for an end zone fault
(1) Tripping command applied to the CB.
(2) CB auxiliary contact sends a signal that the CB is open to
the “CB Off” input of the function which is used to start the
EFP.
(3) The circuit-breaker ruptures the fault current.
(4) After a reset delay plus a safety margin, the current unit either detects that the fault current has been interrupted and
the EFP function resets, or the fault current continues to
flow and an EFP signal is issued.
CB open CB Off Reset tEFP t t t + tMargin
tCB open CB opening time including arc extinction time
tCB Off CB opening time of the CB auxiliary contact
(Signal ?CB open“)
tReset Reset time of the current detector 3)
tMargin Allowance for variations in normal fault clearing time 4)
