TP830底座
編程器連接，并行用于并行接口（僅限MS-DOS編程器）
編程器連接到總線變送器模塊（IC697BEM713），如所示
圖1.查閱適用的編程軟件編程說明的用戶手冊功能。編程器連接，串行端口
CPX 772有三個獨立的板載串行港口。這些端口可通過
模塊前部，用于與編程計算機或其他串行設備。
從固件版本8.00開始，支持程序加載/存儲操作和數(shù)據報
添加到端口1和2。此外，Break-Free SNP是添加為中端口1和2的默認協(xié)議
固件版本8.00。有關詳細信息，請參閱模塊附帶的產品信息表。底部端口3也與RS-485兼容，但不是孤立的。端口3有一個15針內螺紋D連接器。引腳輸出信息可在中找到IC697 PLC安裝手冊。CPX前部的三個LED指示燈928提供上的串行端口活動狀態(tài)CPU，而不連接端子。
這個LED標記為P1、P2和P3，以對應適用的端口。
從CPU串行端口到串行端口的連接編程計算機上的端口或其他串行端口
設備需要一條串行電纜，對于端口2和3轉換器。可以使用IC690ACC901電纜套件（包括電纜和微型轉換器），或者您可以構建電纜以適應
您特定應用的需求。參見IC697有關串行的更多信息，請參閱PLC安裝手冊通信、電纜和轉換器。
編程器連接，以太網TCP/IP通過以太網連接程序員
TCP/IP網絡需要安裝以太網PLC中的接口模塊。這可以是以太網控制器，IC697CMM741或以太網接口（類型2），IC697CMM742。連接前您的編程器和PLC連接到以太網TCP/IP網絡：必須在以太網中設置IP地址
界面設置IP地址后，連接PLC和運行Windows軟件的編程器到以太網接口。更詳細編程器連接信息，通過以太網TCP/IP，參考TCP/IP以太網通信（類型2）用戶手冊，以及Windows編程手冊，GFK-1295
Programmer Connection, Parallel
For a parallel interface (MS-DOS programmer only)
the programmer is connected to the top port on the
Bus Transmitter Module (IC697BEM713) as shown in
Figure 1. Consult the applicable Programming Software
User‘s Manual for a description of programming
functions.Programmer Connection, Serial Ports
The CPX 772 has three independent, on-board serial
ports. These ports, accessed by connectors on the
front of the module, are used for serial interface to a
programming computer or other serial devices.
Starting with Firmware Release 8.00, support for
program Load/Store operations and Datagrams was
added to Ports 1 and 2. Also, Break-Free SNP was
added as the default protocol for Ports 1 and 2 in
Firmware Release 8.00. For details, see the Important
Product Information sheet that ships with the module.Port 3, the bottom port, is also RS-485 compatible,
but is not isolated. Port 3 has a 15-pin, female Dconnector. Pin-out information can be found in
the IC697 PLC Installation Manual.Three of the LED indicators on the front of the CPX
928 provide the status of serial port activity on the
CPU without having a terminal connected. The
LEDs are labeled as P1, P2, and P3 to correspond to
the applicable port.
The connection from a CPU serial port to the serial
port on a programming computer or other serial
device requires a serial cable and, for Ports 2 and 3, a
converter. This connection can be made with the
IC690ACC901 cable kit (includes cable and
miniconverter) or you may build cables to fit the
needs of your particular application. See the IC697
PLC Installation Manual for more information on serial
communications, cables, and converters.
Programmer Connection, Ethernet TCP/IP
Connecting your programmer via an Ethernet
TCP/IP network requires installation of an Ethernet
Interface module in the PLC. This can be either the
Ethernet Controller, IC697CMM741, or Ethernet
Interface (Type 2), IC697CMM742. Before connecting
your programmer and PLC to the Ethernet TCP/IP
network you must set the IP address in the Ethernet
Interface. After setting the IP address, connect the PLC and the programmer running Windows software
to the Ethernet Interface. For more detailed
information on the programmer connection via
Ethernet TCP/IP, refer to the TCP/IP Ethernet
Communications (Type 2) User’s Manual, and the
Windows programming manual, GFK-1295
