手動模式激活
當DECS-100在手動模式下運行時，該LED點亮。手動模式通過以下方式啟用：BESTCOMS軟件。
低頻有源當發電機頻率降低到低于欠頻設定點時，該LED亮起DECS-100在選定的伏特/赫茲曲線上進行調節。通信端口
通信端口位于后面板上，并且包括一個RS-232（DECS-B-9）母接頭。這個通信端口用作編程接口
DECS-100的（設置）。圖2-2說明了通信端口。
編程需要標準的九針串行連接在DECS-100和使用BESTCOMS軟件運行的IBM兼容PC。
BESTCOMS軟件是基于Microsoft Windows?的隨附的通信軟件包DECS-100。提供了最佳通信的詳細說明
第5節，BESTCOMS軟件。本節描述了DECS-100的功能，并解釋了其操作特點。緩和理解，DECS-100功能如圖3-1的框圖所示在DECS-100功能標題下的段落中提供了每個功能塊的說明阻礙。
DECS-100的操作功能包括四種操作模式、四種保護功能、啟動規定，無功下垂補償、低頻補償和可選電壓匹配。詳細的DECS-100標題下的段落中提供了每個操作特征的說明操作特性。
以下段落描述了圖3-1所示的每個功能塊
每個模塊連同所有功能模塊輸入和輸出的操作一起進行說明。
模擬輸入電路七個模擬電壓和電流可被感測并施加到DECS-100。母線電壓
在包含電壓的裝置上的端子B3和B1處監控C相和A相母線電壓匹配。在這些端子處可感測到高達600 Vac的標稱電壓。在此監測的電壓輸入在被應用到模數轉換器（ADC）的輸入之前被縮放和調節。施加到ADC的總線電壓信號用于計算跨接總線電壓的rms值相C和A（總線VC-A）。
發電機電壓在端子E1（A相）、E2（B相）和E3（C相）處監測發電機電壓。名義上的在這些端子處可感測到高達600 Vac的電壓。施加到這些輸入的電壓在被施加到ADC的輸入之前被縮放和調節。
Manual Mode Active
This LED lights when the DECS-100 is operating in Manual mode. Manual mode is enabled through
BESTCOMS software.
Underfrequency Active
This LED lights when the generator frequency decreases below the underfrequency setpoint and the
DECS-100 is regulating on the selected volts per hertz curve.
COMMUNICATION PORT
The communication port is located on the rear panel and
consists of a female, RS-232 (DECS-B-9) connector. The
communication port serves as an interface for programming
(setup) of the DECS-100. Figure 2-2 illustrates the location of
the communication port.
Programming requires a standard, nine-pin, serial
communication cable connected between the DECS-100 and
an IBM-compatible PC operating with BESTCOMS software.
BESTCOMS software is a Microsoft Windows?-based
communication software package that is supplied with the
DECS-100. A detailed description of BESTCOMS is provided
in Section 5, BESTCOMS Software. This section describes how the DECS-100 functions and explains its operating features. To ease
understanding, DECS-100 functions are illustrated in the block diagram of Figure 3-1. A detailed
description of each function block is provided in the paragraphs under the heading of DECS-100 Function
Blocks.
DECS-100 operating features include four operating modes, four protective functions, startup provisions,
reactive droop compensation, underfrequency compensation, and optional voltage matching. A detailed
description of each operating feature is provided in the paragraphs under the heading of DECS-100
Operating Features. The following paragraphs describe each of the function blocks illustrated in Figure 3-1. The function of
each block is explained along with the operation of all function block inputs and outputs.
Analog Input Circuits
Seven analog voltages and current may be sensed and applied to the DECS-100.
Bus Voltage
C-phase and A-phase bus voltages are monitored at terminals B3 and B1 on units that include voltage
matching. Nominal voltages of up to 600 Vac may be sensed at these terminals. Voltage monitored at this
input is scaled and conditioned before being applied to the input of the analog-to-digital converter (ADC).
This bus voltage signal applied to the ADC is used to calculate the rms value of the bus voltage across
phases C and A (Bus VC-A).
Generator Voltage
Generator voltage is monitored at terminals E1 (A-phase), E2 (B-phase), and E3 (C-phase). Nominal
voltages of up to 600 Vac may be sensed at these terminals. Voltage applied to these inputs is scaled and conditioned before being applied to the input of the ADC.
