系統要求MVI56-101M模塊至少需要以下硬件和軟件：組件：羅克韋爾自動化控制? 處理器，具有兼容電源為MVI56-101M模塊提供機架中的一個空閑插槽。模塊需要800 mA的可用功率。
羅克韋爾自動化RSLogix 5000編程軟件版本2.51或較高的羅克韋爾自動化RSLinx通信軟件
奔騰?
II最小450 MHz。奔騰III 733 MHz（或更高）
支持的操作系統：
o帶有Service Pack 1或2的Microsoft Windows XP Professional
o帶有Service Pack 1、2或3的Microsoft Windows 2000 Professional
o Microsoft Windows Server 2003
最小128 MB內存，建議256 MB內存
100 MB的可用硬盤空間（或更多，取決于應用程序要求）
256色VGA圖形適配器，最小分辨率為800 x 600（真彩色1024×768推薦）
ProSoft配置生成器、超級終端或其他終端仿真器
程序注意：您可以將模塊安裝在本地或遠程機架中。對于遠程機架安裝，模塊
需要與處理器進行以太網/IP或ControlNet通信。安裝ProSoft Configuration Builder軟件
您必須安裝ProSoft Configuration Builder（PCB）軟件才能進行配置模塊。您始終可以獲得最新版本的ProSoft配置ProSoft技術網站的建設者。
從ProSoft網站安裝ProSoft Configuration Builder
1.打開web瀏覽器并導航
2.單擊此處下載鏈接下載最新版本的ProSoft配置生成器。
3在提示時選擇保存或保存文件。
4將文件保存到Windows桌面，以便在您已完成下載。
5下載完成后，找到并打開文件，然后按照屏幕上安裝程序的說明。
System Requirements
The MVI56-101M module requires the following minimum hardware and software
components:
Rockwell Automation ControlLogix? processor, with compatible power
supply and one free slot in the rack, for the MVI56-101M module. The module
requires 800 mA of available power.
Rockwell Automation RSLogix 5000 programming software version 2.51 or
higher
Rockwell Automation RSLinx communication software
Pentium?
II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
Supported operating systems:
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
o Microsoft Windows Server 2003
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
ProSoft Configuration Builder, HyperTerminal or other terminal emulator
program.
Note: You can install the module in a local or remote rack. For remote rack installation, the module
requires EtherNet/IP or ControlNet communication with the processor. Installing ProSoft Configuration Builder Software
You must install the ProSoft Configuration Builder (PCB) software to configure
the module. You can always get the newest version of ProSoft Configuration
Builder from the ProSoft Technology website.
Installing ProSoft Configuration Builder from the ProSoft website
1 Open your web browser and navigate to http://www.prosofttechnology.com/pcb
2 Click the DOWNLOAD HERE link to download the latest version of ProSoft
Configuration Builder.
3 Choose SAVE or SAVE FILE when prompted.
4 Save the file to your Windows Desktop, so that you can find it easily when
you have finished downloading.
5 When the download is complete, locate and open the file, and then follow the
instructions on your screen to install the program.
