CSI3120振動變送器
恢復出廠變量參數：要恢復原始出廠變量參數，請拉在“配置”菜單下，選擇“電機”，然后選擇電機族和電機型號。點擊“至驅動”按鈕將變量參數發送到RAM和“RAM/E2
“保存”按鈕保存到EEPROM。
恢復自定義變量參數：此過程假設您保存了自定義變量
參數設置為.SSV文件，如上所述。要恢復自定義參數，請下拉編輯
菜單中，選擇備份變量，然后單擊“打開”。突出顯示要導入變量的自定義.SSV文件
參數輸入編輯器。單擊“Xmit”將變量參數發送到驅動器。
終端模式
使用MOTIONLINK終端模式（或任何其他“啞”主機）直接監控或修改
變量設置和命令驅動器。這種方法僅適用于帶有Windows的PC操作系統不可用和/或您熟悉變量和命令集。
每個變量和命令都引用其語法和參數定義。變量和命令按字母順序分組，便于查找，并在本手冊末尾找到。確信在開始之前，請查看此信息。
初始啟動
大多數驅動器出廠時已為特定電機配置。你可以證實這一點
通過施加邏輯電源并監控狀態顯示。工廠配置的驅動器通過
通電順序：在穩定到指示
操作模式。如果驅動器未配置特定電機，顯示屏將閃爍負號符號“-”，表示必須輸入驅動器、電機和應用程序變量參數。其余的本節的介紹了設置未配置驅動器的過程。
向驅動器通電時必須小心。工廠配置為：通電后啟用。
驗證硬件遠程啟用
（遠程）啟用開關被禁用。
通電后，伺服星執行一系列自檢。如果狀態顯示點亮，則實數，則未發現錯誤，EEPROM已加載其可變參數（或已加載在EEPROM數據無效的情況下具有默認值）輸入RAM。I/O上的遠程啟用開關
連接器（C3）現在可以通電，從而啟用伺服回路。驅動啟用邏輯基于以下變量開關和標志：
激活：這是指示驅動器啟用/禁用狀態的總體就緒標志。如果高（1） ，驅動器已啟用，電機正在通電。下式必須為真才能使活動變高：活動=（就緒）和（遠程）
其中就緒=（DRIVEOK）和（SWEN）
就緒：表示驅動器無故障且已準備好硬件啟用的標志。
DRIVEOK（驅動器正常）：開關指示驅動器故障的狀態。
SWEN：開關指示軟件啟用狀態（EN或DIS）。
遠程：開關指示C3連接器上硬件遠程啟用線路的狀態。
