A6500-UM通用測量卡
按ENTER鍵打開系統控制器子菜單，其中VMEbus系統資源被配置。
VME字節交換此字段用于配置VMEbus主和從字節交換選項。這個選項包括字節交換全部（默認）、字節交換從屬、字節交換主和禁用。
主界面按ENTER鍵打開主界面子菜單，其中VMEbus主界面接口已配置。
從屬接口這是標題，不是字段。從機1和2運行模式
此字段允許配置VMEbus從設備1和2。選項包括可編程（默認）且兼容。選擇可編程允許您：配置和啟用VMEbus從站1和2，就像從站3、4、5、6、7和8一樣。選擇兼容時，BIOS會自動配置并啟用VMEbus
從設備1和2。兼容設置XVME-660從設備接口，以便與未使用的舊Xycom Automation VME PC處理器板兼容宇宙芯片。
sla這些字段確定的前12位的基本VMEbus地址前綴
VMEbus從接口將響應的地址。這三個字段是這12位的高（H）、中（M）和低（L）半字節。地址為HML00000h。在默認屏幕配置中，H為A，M為A，L為4，因此地址為AA400000h。
這些值根據大小和地址空間字段值而變化。當?shù)刂房臻g值為VMEbus標準，必須定位雙訪問存儲器
在1 MB邊界上，上兩個半字節被忽略，因此高和中半字節變?yōu)?，并變?yōu)橹蛔x。當?shù)刂房臻g值為VMEbus擴展時，從屬地址必須是從屬內存大小的倍數。當大小大于1 MB時，低半字節被截?cái)酁榕紨?shù)。
注意：使用這些字段設置的地址是VMEbus處理器。XVME-660上的PC/AT處理器將看到翻譯的
住址此轉換（以及轉換量）由BIOS和計算在BIOS設置中不可由用戶配置。關于翻譯的討論見第67頁地址。進行應保存的更改后，始終選擇退出或保存更改或保存更改。這兩個過程都將更改存儲在電池支持的CMOS RAM中。
下次啟動計算機時，BIOS將根據設置選擇存儲在CMOS中。如果這些值導致系統引導失敗，重新啟動并進入BIOS設置。在BIOS設置中，您可以加載默認值（加載設置默認值）或嘗試更改導致啟動失敗的選擇。
