DATX130數字量工控卡件
Advme7509是一個使用PowerPC750FX的單槽6U VME板加工機該板可用作系統控制器，以滿足高性能和系統要求。前面板包括2ch的10/100BASE-TX以太網端口和4ch RS232串行端口。
各種存儲器，包括SDRAM（高達512MB）、CompactFlash、閃存和閃存，可提供閃存、SRAM和EEPROM。外部VME總線可通過車載“鳴人II”PCI-VME橋訪問。
?單槽6U VME PowerPC處理器板
?利用IBM PowerPC750FX（600MHz）CPU，配備32K字節一級緩存和512k字節二級緩存
?Marvell的Discovery I（GT-64260）系統控制器
?高達512MB的雙端口SDRAM（133.3MHz，EC/ECC），可從VME總線
?8通道DMA控制器，用于主存儲器和內部PCI總線
?2信道10/100Base TX以太網
?4通道RS232C串行端口和4通道RJ-45端口
?512k字節啟動ROM閃存，可容納Advantet T4th啟動裝載
?512k字節SRAM和實時時鐘，由鋰電池備份
?小型閃存插座
?256字節串行EEPROM（非易失性存儲器）
?單個64位/66MHz PMC插槽
?通過Advanet的“NARUTO II”PCI-VME橋與VME總線接口
?可作為VME主設備或從設備運行
?需要來自VME總線的單個5V電源。TSDiag+是一種工具，允許您使用Microsoft CE或通過網絡使用Windows XP操作系統的計算機。
由操作系統和客戶端/服務器組成的每個組合都是可能的。用戶可以查看顯示器的內容，并與正在運行的軟件進行交互在設備上，無論軟件制造商如何。在這種情況下，您可以執行與直接操作觸摸屏時相同的操作。你可以也可以使用訪問設備的鍵盤-PC或其他操作設備-輸入數據，而無需通過您正在訪問的設備的輸入面板進行替代路由。
該選項提供了額外的功能增強，允許您將文件傳輸?shù)皆O備中可以寫入的任何文件夾。
因此，您可以使用TSDiag+從一個計算機連接到多個操作設備或檢查當前運行的應用程序的當前狀態。
2.1一般操作條件
該軟件可在Windows CE 5.0和6.0操作系統的設備上執行。該客戶端也可用于使用x86架構的PC。為了在客戶端和服務器之間建立通信，服務器并且客戶端必須在網絡內的同一子網中。
操作設備所需的內存量非常低-服務器和客戶端的組合內存需求小于500 KB。此外還有日志文件所需的內存。但是，其大小由設置決定。PC的客戶端需要少于50 KB的硬盤。
Advme7509 is a single-slot 6U VME board utilizing a PowerPC750FX
processor. The board can be used as a system controller to meet high
performance system requirements. The front panel includes 2ch of
10/100BASE-TX Ethernet ports and 4ch RS232 serial ports.
A variety of memory, including SDRAM (up to 512MB), CompactFlash,
FlashROM, SRAM, and EEPROM are available. The external VME bus
is accessible via the on-board “NARUTO II” PCI-VME bridge.
? Single-slot 6U VME PowerPC processor board
? Utilizing IBM PowerPC750FX (600MHz) CPU with 32K bytes L1 cache & 512k
bytes L2 cache
? Marvell’s Discovery I (GT-64260) system controller
? Up to 512MB of dual-ported SDRAM (133.3MHz, EC/ECC) accessible from
the VME bus
? 8-ch DMA controller for high speed transfers between main memory and the
internal PCI bus
? 2-ch 10/100Base-TX Ethernet
? 4-ch RS232C serial ports and 4-ch RJ-45 ports
? 512k bytes Boot ROM FLASH memory accommodating an Advanet T4th boot
loader
? 512k bytes SRAM and real time clock, backed up with a lithium battery
? Socket for CompactFlash memory
? 256 bytes serial EEPROM (non-volatile memory)
? A single 64-bit / 66MHz PMC slot
? Interface with the VME bus sing Advanet’s “NARUTO II” PCI-VME bridge
? Can operate as either a VME master or slave
? Requires a single 5V power supply from the VME bus TSDiag+ is a tool that allows you to access each Sütron operating device using the
Microsoft CE or a computer using the Windows XP operating system via the network.
Each combination consisting of operating system and client / server is possible.
The user can view the content of the display and interact with the software running
on the device, regardless of the software manufacturer. In this case, you can perform
the same actions that you can when operating the touch screen directly. You can
also use the keyboard of the accessing device - a PC or another operating device -
to enter data without the need for an alternative routing via the input panel of the device that you are accessing.
Additional functional enhancement is provided by the option that allows you to transfer files to any folder in the device that can be written to.
As a result, you can use TSDiag+ to transfer updated project files or drivers from one
computer to multiple operating devices or to check the current status of the application currently running.
2.1 General Operating Conditions
The software is executable on devices with Windows CE 5.0 and 6.0 operating system. The client is also available for PCs using the x86 architecture.
To enable communication between client and server to be established, the server
and the client must be in the same subnet within the network.
The amount of memory required on the operating devices is very low - the server and
client have a combined memory requirement of less than 500 KB. Added to this is
the memory required by the log file. However, its size is determined by the settings.The client for the PC requires less than 50 KB on the hard disk.
