SCHUMACHER ATCS-15 1464-0320模塊庫存
遠程模塊故障排除
遠程模塊的診斷功能遠程模塊配備了許多診斷功能。其中一些功能成為僅當它們已通過I/O設置時才處于活動狀態配置功能完全可用。設置和錯誤可以從相關頻道進行詢問。部分功能可用，請參閱模塊說明。1） 關于設置和診斷數據，請參見模塊說明和第A3.3章“讀取I/O配置和模塊上的診斷數據”。BE總線錯誤=總線故障，始終受到監控。這個模塊未收到來自總線主設備的呼叫。
這可能有以下原因：
–CS31系統總線斷開，短路或接線極性相反。
–中央單元未設置為“終結者”主，另見系統常數KW 00,00 in第A7.3章。
CI輸入斷線=斷路（監控）
輸入（如果已配置）。每個輸入電路監控裝置必須配備一個電阻20…30 k，例如與信號觸點并聯。CO切斷輸出線=斷路（監控）輸出（如果已配置）。每個輸出都需要當ON信號為輸出OL過載（始終受到監控）。
SC短路（始終受到監控）。UE單元錯誤=模塊的內部錯誤（故障）（始終盡可能監控內部處理器檢測到這一點）。遠程模塊中的故障排除
如果遠程模塊檢測到，則LED亮起一個錯誤。遠程模塊提供詳細的錯誤信息通過8個LED，按下測試按鈕；看見以及模塊說明。以下將對程序進行解釋以ICSC 08 L1模塊為例。第一次按下測試按鈕后，選擇通道E/A0（輸入/輸出0）：LED0閃爍。松開按鈕后此通道通過黃色LED 0至7顯示約3秒。
Troubleshooting on the remote modules
Diagnosis functions for the remote modules
The remote modules are equipped with a number of
diagnosis functions. Some of these functions become
active only if they have been set by means of the I/O
configuration
Feature is completely available. Settings and errors can be interrogated from the involved channel. () Feature is partly available, see module description. 1) Concerning the interrogation of settings and diagnosis data, see the module description and chapter A3.3 ”Reading I/O configuration and diagnosis data at the module”. BE Bus Error = Bus malfunction, always monitored. The module does not receive a call from the bus master. This may have the following reasons: – The CS31 system bus line is broken, short-circuited or wired with reversed polarity. – The central unit has< not been set as buster master, see also system constant KW 00,00 in chapter A7.3. CI Cut Wire of Inputs = Open circuit (monitoring) at inputs, if configured. Each input circuit to be monitored has to be equipped with a resistor of 20...30 k, e.g. in parallel to the signalling contact. CO Cut Wire of Outputs = Open circuit (monitoring) at outputs, if configured. Each output expects a minimum load of approx. 40 mA when an ON signal is output. OL Overload (is always monitored). SC Short circuit (is always monitored). UE Unit error = internal error (fault) of the module (always monitored in so far as the internal processor can detect this). Troubleshooting in the remote modules The LED lights up, if the remote module has detected an error. The remote module supplies detailed error information via the 8 LEDs , it the test button is pressed; see also the module descriptions. The procedure will be explained in the following for the module ICSC 08 L1 as an example. After the test button has been pressed for the first time, channel E/A0 (input/output 0) is selected: LED0 flashes. After the button has been released, The diagnosis data of this channel are shown via the yellow LEDs 0 to 7 for approx. 3 seconds.
