二次回路及控制
控制系統由控制器，IO板和人機界面組成。控制器由三塊光纖板，一塊信號板，一塊主控板和一塊電源板組成。各部分之間的聯系如下圖HIVERT變頻器控制系統結構圖所示。
圖3 HIVERT變頻器控制系統結構圖
2.變壓器柜
高壓水冷變頻器采用干式移相隔離變壓器。絕緣等級為H級。額定容量為12500kVA。
3.功率單元柜
6kV變頻器每相6個功率單元串聯，單元采用前側排列方式。同相的6個單元由銅排或電纜串聯并且三相的第一個單元短接成Y接中心點，三相的第六個單元即為變頻器的三相高壓輸出。功率單元額定電壓690V，變頻器的額定輸入/輸出電壓為6kV。正面右側為二次控制室，安裝有控制器、電源開關等，用戶二次接線端子也布置在控制室內。
功率單元采用水冷設計，安裝在導軌上，由兩個M8的螺釘與導軌固定。單元柜后側為水循環管路，把功率單元內產生的熱量帶到水-水熱交換器，由外水循環系統將內水熱量帶走。柜門內側裝有行程開關，用于柜門連鎖，柜門打開時將發出告警。
3.1單元柜水冷循環系統
水冷分內循環和外循環兩部分。內循環部分，變頻器功率單元采用水冷板散熱，去離子水通過管道進入水冷板，將IGBT等功率元件熱量傳遞給去離子水后，由去離子水帶走，進入水-水熱交換器，水-水熱交換器通過和外循環水換熱，把熱量由外循環水帶走，冷水進入單元水冷板繼續循環。
4.冷卻方式
據現場實際情況、投資、運營、可靠性及維護成本，采用風-水冷卻系統方案。
4.1 風路循環
冷卻變頻器后的熱空氣由風機從柜頂導出，通過風道循環至換熱器，換熱器中通有冷卻水，從而使空氣得以冷卻降溫，冷卻降溫后的空氣再次進入變頻器對變頻器進行冷卻，如此進行循環冷卻。to illustrate with pictures with SIMATIC s7-1200 control cabinet or products.
