MVME712-103通用電氣卡件
或參數、信號和故障驅動器窗口2 4-133 15.1.2要導出驅動器中的參數在瀏覽樹窗格中，用鼠標右鍵單擊驅動器（或其中的子分支），然后在上下文菜單的參數子菜單中選擇導出命令?；蛘撸绻?xí)慣于使用普通菜單，請選擇（單擊）驅動器（或其中的子分支），然后從“文件”菜單中“參數”子菜單的“導出”子菜單中選擇“選定”命令?；?5.1.3要導出所有驅動器的參數，請選擇“文件”菜單中“參數”子菜單的“導出”子菜單中的“所有驅動器”命令。請注意，即使打開了參數文件，它也不會隨驅動器一起導出。15.1.4要導出參數差異當您在“參數比較”對話框中查看差異時，單擊“導出”按鈕。參數、信號和故障4-134驅動窗口2 15.1.5顯示導出對話框時：不同導出中顯示的對話框僅因標題欄中顯示的文本而異。?從“另存為類型”中，選擇導出格式。?從“保存位置”瀏覽到要將參數或差異導出到其中的驅動器和目錄。?在文件名中輸入導出文件的名稱，如果要替換現有文件，請單擊要替換的文件名。?單擊保存并請求文件注釋。如果文件已經存在，單擊“保存”時會詢問是否要替換該文件。15.1.6顯示“文件注釋”對話框時：編輯字段中有一個時間戳作為默認注釋。它被選中，這意味著如果您剛開始鍵入，它將被您的注釋所取代。參數、信號和故障DriveWindow 2 4-135?在編輯字段中輸入、添加、編輯或接受注釋?單擊“確定”，然后開始導出注意，注釋實際上由一行組成，盡管它在編輯字段內自動換行和滾動。按下Enter鍵實際上與單擊OK按鈕相同。如果以XML格式導出，并且希望注釋由多行組成，請使用Ctrl+J鍵開始一行。編輯時，可以使用普通的Windows快捷鍵和編輯鍵，如箭頭鍵、Home鍵、End鍵、Del鍵等，也可以使用Ctrl鍵和/或Shift鍵。
or Parameters, Signals, and Faults DriveWindow 2 4-133 15.1.2 To export parameters in a drive In the browse tree pane, click with the right mouse button the drive (or a sub-branch within it), then select the Export command in the Parameters submenu of the context menu. Or, if you are more accustomed to use normal menus, select (click) the drive (or a sub-branch within it), then select the Selected command from the Export submenu of the Parameters submenu in the File menu. or 15.1.3 To export parameters of all drives Select the All Drives command in the Export submenu of the Parameters submenu in the File menu. Note that even if you have a parameter file open, it is not exported with drives. 15.1.4 To export parameter differences When you are viewing the differences in a Parameter Comparison dialog box, click the Export button. Parameters, Signals, and Faults 4-134 DriveWindow 2 15.1.5 When the Export dialog box is displayed: The dialog boxes shown in different exports differ only by the text shown in the title bar. ? From Save as type, select the export format. ? From Save in, browse into the drive and directory, into which you want to export the parameters or the differences. ? Enter the name of the export file into File name or, if you want to replace an existing file, click the filename you want to replace. ? Click Save and a file comment is requested. If the file already exists, confirmation to replace it asked when you click Save. 15.1.6 When the File Comment dialog box is displayed: There is a time stamp in the edit field as a default comment. It is selected, which means that if you just start typing, it is replaced by your comment. Parameters, Signals, and Faults DriveWindow 2 4-135 ? Enter, add, edit, or accept the comment in the edit field ? Click OK, and exporting starts Note that the comment actually consists of one line, although it automatically wraps and scrolls within the edit field. Pressing the Enter key is actually the same as clicking the OK button. If you are exporting in XML format and you wish your comment to consist of several lines, use the Ctrl+J key to start a new line. While editing, you can use the normal Windows shortcut and editing keys like the arrow keys, Home, End, Del, etc. keys, with or without Ctrl and/or Shift key down.
