（僅限彩色打印機）和線條樣式。彩色和黑白打印機的首選項是分開的。13打印注意，無法打印正在運行的監視器。如果圖形光標可見，則也會打印。滾動條不打印。要打印當前顯示在趨勢顯示窗格中的趨勢，請在文件菜單的圖形子菜單或監視器顯示或數據記錄器顯示的上下文菜單中選擇打印命令?；騎rends DriveWindow 2 6-111顯示打印設置對話框。現在，您可以選擇打印機、紙張大小、方向和來源。您還可以通過單擊“屬性”按鈕進行打印機相關的調整。請注意，打印圖形時，圖形會自動展開以填充所選紙張的打印區域。例如，如果您的打印機支持A4和A3，則將紙張大小從A4增加到A3會將打印輸出放大一倍。您可能希望打印輸出與屏幕上顯示的相同。因此，應將紙張方向設置為橫向。請注意，如果單擊“取消”按鈕，則不會取消打印。相反，您所做的任何設置更改都將被丟棄。效果與單擊“確定”而不進行任何設置更改時的效果相同。接下來將顯示“編輯圖形標題”對話框。如果您有黑白打印機，請取消選中“以顏色打印”復選框。如果您有彩色打印機，請選中“以彩色打印”復選框。DriveWindow已使用其默認值填充編輯字段。如果愿意，可以在對話框的編輯字段中編輯自己的標題（或注釋）。它們將位于打印輸出的上部。準備就緒后，單擊“確定”。prn/b LPT1：如果您沒有打印機驅動程序，或者您的打印機驅動程序無法打印到文件，建議您安裝Adobe Acrobat PDF打印機（包含在Adobe Acrobat中），它允許您以PDF格式打印到文件。其他具有此類功能的打印機驅動程序也可以完成此項工作。12打印首選項在圖形首選項中，您可以控制打印趨勢的前景。你可以改變趨勢的顏色
(color printer only) and line styles. The preferences are separate for color and black-and-white printer. 13 Printing Note that printing of a running monitor is not possible. If you have the graph cursor visible, it is printed, too. The scrollbars are not printed. To print the trends currently displayed in the trend display pane, select the Print command in the Graph submenu of the File menu or in the context menus of Monitor Display or Datalogger Display. or Trends DriveWindow 2 6-111 A Print Setup dialog box is presented. Now you can select the printer, paper size, orientation, and source. You can also do printer dependent adjustments by clicking the Properties button. Note that when a graph is printed, it is automatically expanded to fill the printing area of the selected paper. If your printer supports A4 and A3, for example, doubling the size of the paper from A4 to A3 magnifies the printout to double, too. You probably want the print-out to look the same as it is displayed on your screen. So, you should set the paper orientation to landscape. Note that if you click the Cancel button, it does not cancel printing. Instead, any setup changes you made are discarded. The effect is the same as if you had clicked OK without making any setup changes. An Edit Graph Titles dialog box is presented next. If you have a black and white printer, please uncheck the Print in Color check field. If you have a color printer, please check the Print in Color check field. DriveWindow has filled the edit fields with its default values. If you wish, you can edit your own titles (or comments) into the edit fields of the dialog box. They will be located at the upper part of the print-out. When you are ready, click OK.prn/b LPT1: If you do not have a printer driver, or your printer driver is not able to print to a file, we recommend that you install Adobe Acrobat PDF Printer (included in Adobe Acrobat), which allows you to print to a file in PDF format. Some other printer driver with such kind of feature will also do the job. 12 Preferences for printing In graph preferences you can control outlook of the printed trends. You can change colors of the trends
