MVME2700-1461工業備件
我們還假設您使用的是通用的而不是個性化的工作空間偏好。如果您使用的是個性化工作區首選項，DriveWindow將使用“我的文檔”的DriveWare文件夾中的用戶特定DW21.INI，而不是ProgramData的DriveWare文件夾中的通用DW21.INI。同時討論以XML格式打印和導出的原因是，即使您請求打印，DriveWindow也會以XML格式導出。唯一的區別是，在導出而不是打印時，對XSL樣式表文件的引用被注釋掉。此外，通過打印創建的XML文件是臨時的，當它退出時，DriveWindow會刪除它。高級信息DriveWindow 2 10-35導出時，DriveWindow會詢問XML文件的名稱，然后導出，操作完成。打印時，導出的時態XML文件將移交給Internet Explorer（組件），Internet Explorer使用XML文件引用的XSL樣式表將XML轉換為HTML，并執行打印（除非DW21.INI文件中另有指定）。注意，如果打印，則需要安裝IE6（或更高版本），因為它是第一個使用MSXML3的版本，可以進行XSL轉換。DriveWindow創建的XML文件包含對架構定義（XSD）的引用，該定義可用于驗證XML。您需要使用MSXML4或更高版本來驗證XML。然而，IE6始終使用MSXML3，即使您安裝了MSXML的更新版本（并排）。因此，雖然存在機制（用于IE的未來增強），但XML沒有得到驗證。DriveWindow使用DW21.INI確定用于不同類型打印的XSL和可選CSS文件。通常，DW21.INI中沒有添加任何內容，這意味著使用默認值。另請參閱：如何打印參數打印項目集配置打印后期幫助文件和自定義打印特殊打印功能無模型打印的后果12.1配置打印由于打?。ǘ皇勤厔荩┦怯蒊nternet Explorer（用作組件）完成的，IE的設置也會影響DriveWindow的打印輸出。?頁面設置與IE通用，但紙張方向除外，在DriveWindow中打印時始終重置。?高級IE設置“打印背景顏色和圖像”也會影響DriveWindow中打印的外觀。我們建議您使用DriveWindow打印背景色和圖像。高級信息10-36 DriveWindow 2最后提到的IE設置可以通過從“工具”菜單中選擇“Internet選項”，選擇“高級”選項卡，然后瀏覽“打印”來找到。高級信息DriveWindow 2 10-37另請參閱：以XML格式打印和導出12.2打印DriveWindow中的后期打?。ㄚ厔莩猓┦鞘褂肐nternet Explorer版本6（或更高版本）作為組件完成的。如果沒有安裝正確的組件，DriveWindow中的打?。ㄚ厔莩猓⒈唤茫ɑ疑?/p>
We also assume that you are using common instead of personalized workspace preferences. If you are using personalized workspace preferences, DriveWindow uses the user specific DW21.INI in the DriveWare folder of My Documents instead of the common DW21.INI in the DriveWare folder of ProgramData. The reason, why printing and exporting in XML-format are discussed together, is that DriveWindow actually exports in XML format even when you request printing. The only difference is that the reference to the XSL style sheet file is commented out when you are exporting instead of printing. Also the XML file created by printing is temporal and DriveWindow deletes it when it is exiting. Advanced Information DriveWindow 2 10-35 When you export, DriveWindow asks the name of the XML file, exports, and the operation is done. When you print, the exported temporal XML file is handed over to Internet Explorer (component), which uses the XSL style sheet referenced by the XML file to convert XML to HTML, and also does the printing (unless otherwise specified in the DW21.INI file). Note that if you print, you need to have IE 6 (or newer) installed, because it is the first version that uses MSXML3, which can do XSL transformations. The XML file created by DriveWindow contains reference to the schema definition (XSD), which can be used to validate the XML. You need to use MSXML4 or newer to validate the XML. However, IE 6 always uses MSXML3, even if you have a newer version of MSXML installed (side by side). So, the XML is not validated although the mechanism is there (for future enhancements of IE). DriveWindow uses DW21.INI to determine the XSL and optional CSS files to be used for different kinds of printing. Normally there is nothing added into DW21.INI, which means that the defaults are used. See Also: How to Print Parameters Printing Item Sets Configuring Printing Printing Later Helper Files and Customising Printing Special Printing Features Consequences of Modeless Printing 12.1 Configuring Printing Because printing (other than trends) is done by Internet Explorer (used as a component), settings of IE affect the print-out of DriveWindow, too. ? Page Setup is common with IE, except paper orientation, which is always reset when printing in DriveWindow. ? The advanced IE setting “Print Background Colors and Images” affects outlook of printing in DriveWindow as well. We recommend that you do print background colors and images with DriveWindow. Advanced Information 10-36 DriveWindow 2 The last mentioned IE setting can be found by selecting Internet Options from the Tools menu, selecting the Advanced tab, and browsing for Printing. Advanced Information DriveWindow 2 10-37 See Also: Printing and Exporting in XML Format 12.2 Printing Later Printing (other than trends) in DriveWindow is done by using Internet Explorer version 6 (or newer) as a component. If you do not have proper components installed, printing (other than trends) is disabled (grayed) in DriveWindow.
