MVME147-014A機械設備卡件
溫度額定值所有產品工作溫度-3060°C（-22140°F）僅適用于854J-BSF5C：-3045°C（22113°F）存儲溫度-3085°C，和透鏡聚碳酸酯燈插座聚碳酸酯橡膠密封件和墊圈丁腈橡膠桿（鋁桿組件）鋁桿底座底座（鋁桿底座）聚碳酸酯安裝螺釘墊圈聚丙烯性能等級描述24V/120V 240V光輸出頻閃LED 4430 mcd 3915 mcd綠色4216 mcd 4080 mcd琥珀色4430 mcc 3915 mcc藍色1673 mcd 1619 mcd白色4464 mcd 4320 mcd黃色3715 mcd 3283 mcd穩定/閃爍LED 1793 mcd 2392 mcd綠色1714 mcd 3400 mcd琥珀色1793 mcc 2392 mcc藍色680 mcd 1349 mcd白色1814 mcd 3600 mcd黃色1503 mcd 2006 mcd工作電壓描述24V/120V 240V光模塊和聲音模塊24V/（±10%）110V、50Hz（±10%%）120V、60Hz（±10%，60 Hz（±10%）額定壽命（設計壽命）靜態、無振動、，條件描述24V/120V 240V LED 50000小時聲音模塊20000小時羅克韋爾自動化出版物854-SG001C-EN-P-2016年2月11日公告854J-40控制塔Stk燈電流消耗描述24V/1220V 240V僅光模塊穩定LED 22 mA（琥珀色和黃色）33 mA（綠色、藍色和白色）30 mA（琥珀黃色和黃色）29 mA（綠色，藍色和白色閃爍LED 28 mA（、琥珀色和黃色）36 mA（綠色、藍色和白色）30 mA（、黃色和黃色）29 mA（綠色和藍色）頻閃LED 35 mA（、綠色和黃色）65 mA（綠色，藍色和白色模塊大約2 Hz（閃光持續時間1/50000秒）音調頻率屬性值音調頻率預設為2500 Hz分貝額定值（聲音模塊）所有dB（A）額定值在距離聲音模塊1米處確定。屬性值單音聲音模塊（SA3）最大音量輸出為80 dB（A）（不可調）泄漏電流Impt所有光模塊和聲音模塊可以在不激活模塊的情況下吸收固態輸出的高達3 mA的泄漏。12羅克韋爾自動化出版物854-SG001C-EN-P-2016年2月公告854J-40控制塔Stk燈近似尺寸尺寸單位為毫米（英寸）。尺寸不用于制造目的。
Temperature Ratings All Products Operating Temperature -3060 °C (-22140 °F) For 854J-BSF5C only: -3045 °C (-22113 °F) Storage Temperature -3085 °C (-22185 °F) 10 Rockwell Automation Publication 854-SG001C-EN-P - February 2016 Bulletin 854J - 40 Control Tower Stk Lights Materials Attribute Value Bases, Caps, Lens Covers, Sound Module Housings, and Lenses Polycarbonate Lamp Socket Polycarbonate Rubber Seals and Gaskets Nitrile Rubber Pole (for aluminum pole assembly) Aluminum Pole Base Footing (for aluminum pole base) Polycarbonate Mounting Screw Washers Polypropylene Performance Ratings Description 24V / 120V 240V Light Output Strobe LED 4430 mcd 3915 mcd Green 4216 mcd 4080 mcd Amber 4430 mcd 3915 mcd Blue 1673 mcd 1619 mcd White 4464 mcd 4320 mcd Yellow 3715 mcd 3283 mcd Steady/Flashing LED 1793 mcd 2392 mcd Green 1714 mcd 3400 mcd Amber 1793 mcd 2392 mcd Blue 680 mcd 1349 mcd White 1814 mcd 3600 mcd Yellow 1503 mcd 2006 mcd Operating Voltage Description 24V / 120V 240V Light Modules and Sound Modules 24V / (± 10%) 110V , 50 Hz (± 10%) 120V , 60 Hz (± 10%) 230V , 50 Hz (± 10%) 240V , 60 Hz (± 10%) Life Ratings (Design Life) Average Life Under Static, No Vibration, Conditions Description 24V / 120V 240V LED 50,000 hr Sound Modules 20,000 hr Rockwell Automation Publication 854-SG001C-EN-P - February 2016 11 Bulletin 854J - 40 Control Tower Stk Lights Current Consumption Description 24V / 120V 240V Light Only Modules Steady LED 22 mA (, amber, and yellow) 33 mA (green, blue, and white) 30 mA (, amber, and yellow) 29 mA (green, blue, and white) Flashing LED 28 mA (, amber, and yellow) 36 mA (green, blue, and white) 30 mA (, amber, and yellow) 29 mA (green, blue, and white) Strobe LED 35 mA (, amber, and yellow) 65 mA (green, blue, and white) 10 mA Sound Modules Single-tone Sound Module 65 mA 31 mA 32 mA Flashing Frequency (Light Only Modules) Attribute Value Flashing LED Modules Approximately 1.5 Hz Time On/Time OFF = 1:1 LED Strobe Modules Approximately 2 Hz (flash duration 1/50,000 second) Tone Frequency Attribute Value Tone Frequency Preset at 2500 Hz Decibel Rating (Sound Modules) All dB(A) ratings determined at a distance of 1 meter from sound module. Attribute Value Single Tone Sound Module (SA3) Maximum volume output is 80 dB(A) (non-adjustable) Leakage Current Impt All light modules and sound modules can absorb up to 3 mA of leakage from solid-state outputs without module tivation. 12 Rockwell Automation Publication 854-SG001C-EN-P - February 2016 Bulletin 854J - 40 Control Tower Stk Lights Approximate Dimensions Dimensions in millimeters (inches). Dimensions are not intended to be used for manufturing purposes.
