所示轉子慣性值適用于非制動編碼器電機。制動器和分解器版本的電機的慣量更高。增量編碼器和解析器版本的尺寸有限。出版物MP-PP001O-EN-P–2012年3月版權所有?2012 Rockwell Automation，Inc.保留所有權利。在美國印刷，取代出版物MP-P001N-EN-P–2008年12月連接器和電纜MP系列低慣量電機的新型SpeedTEC DIN連接器版本，允許連接器靈活定向，并可將單個電纜系列用于所有MP系列電機。SpeedTEC DIN連接器旨在提供快速的四分之一圈連接。這提供了一個簡單而安全的伺服連接。連接器符合廣泛的規范和標準要求：UL認證的NFPA 79柔性DESINA電纜jket著色托盤電纜額定值RoHS和REH 600V絕緣額定值電機電纜羅克韋爾自動化為您的MP系列電機提供全面的電源、饋電和制動電纜選擇。配件包括標準和連續流動電纜，長度從1米到90米不等。連續流動的電力和制動電纜符合RoHS和NFPA-79托盤等級，由UL認證的散裝電纜組成。Jket顏色符合DESINA規范。電機附件軸封套件適用于MP系列低慣量電機的所有框架尺寸。如果安裝正確，密封件在軸上的防護等級為IP66。注意，軸封是需要定期補充的易損件。請參閱《運動控制選擇指南》，為您的特定電機選擇軸封套件。大多數MP系列電機可使用電機端連接器套件?？蛻暨x擇自己制造電纜時使用這些電纜。該套件采用金屬套管，對電纜jket進行壓縮式密封，并根據套件的不同，采用焊接式或壓接式連接器插座。羅克韋爾自動化為壓接式插座提供壓接工具。有關更多信息，請參閱我們的網站：.ab./motion或Kinetix選擇指南GMC-SG001x。Allen-Bradley和Kinetix是羅克韋爾自動化的注冊商標。SERCOS interfe是德國斯圖加特利益集團SERCOS interfe e.V的商標。
Rotor inertia values shown are for non-brake encoder motors. Inertias are higher for brake and resolver versions of the motors. The incremental encoder and resolver versions are available in limited sizes. Publication MP-PP001O-EN-P – March 2012 Copyright ? 2012 Rockwell Automation, Inc. All Rights Reserved. Printed in USA. Supersedes publication MP-PP001N-EN-P – December 2008 Connectors and Cables New SpeedTEC DIN connector versions of MP-Series Low-Inertia Motors allow fl exible orientation of connectors and use of a single cable family with all MP-Series motors. The SpeedTEC DIN connectors are designed to provide a quick, one-quarter turn connection. This provides an easy, yet secure servo connection. The connectors meet a wide range of codes and standard requirements: UL-Listed NFPA 79 pliant DESINA cable jket coloring Tray cable rating RoHS and REH 600V insulation rating Motor Cables Rockwell Automation off ers a prehensive selection of power, feedbk, and brake cables for your MP-Series motors. Off erings include standard and continuously fl exing cables, in lengths ranging from 1 meter to 90 meters. The continuously fl exing power and brake cables ply with RoHS and NFPA-79 tray ratings, and are posed of UL-listed bulk cable. Jket coloring is pliant with DESINA specifi cations. Motor cessories Shaft seal kits are available for all frame sizes of the MP-Series Low Inertia motors. When installed correctly, the seals yield an IP66 rating at the shaft. Note that shaft seals are wearing parts that will need to be repled periodically. Refer to the Motion Control Selection Guide to select the shaft seal kit for your specifi c motor. Motor-end connector kits are available for most MP-Series motors. They are used by customers who choose to build their own cables. The kits utilize metallic bkshells, pression-style sealing to the cable jket, and are solder-style or crimp-style connector sockets depending on the kit. Crimping tools are off e by Rockwell Automation for crimp-style sockets. For more information refer to our website: .ab./motion, or the Kinetix selection guide, GMC-SG001x. Allen-Bradley and Kinetix are registe trademarks of Rockwell Automation. SERCOS interfe is a trademark of Interests Group SERCOS interfe e.V of Stuttgart, Germany.
