HIMA F8621A系統模塊卡件
5： RX3i系統使用一個通用背板和一個擴展背板1.5.2使用多個擴展和遠程背板以下兩個示例系統彼此相似，但背板之間的距離不同。左側的示例包括兩個RX3i擴展背板和一個Series 90-30擴展背板。擴展背板可以是RX3i（IC694）和Series 90-30（IC693）擴展背板的任意組合。系統中的I/O模塊可以是RX3i和Series 90-30模塊的任意組合。在右側的示例中，兩個背板的安裝必須超出擴展系統的15米（50英尺）限制。在這些位置使用兩個Series 90-30遠程背板。兩個示例系統的所有其他功能都相同，包括其I/O模塊。PACSystems*RX3i系統手冊第2節GFK-2314T 2019年9月簡介18 RX3i擴展背板IC694CHS398 RX3i通用背板IC695CHS012 RX3i擴充背板IC694C HS392系列90-30擴充背板IC691CHS392 I/O端接插頭IC693ACC307最大電纜長度：15米（50英尺）圖6：使用多擴展背板的RX3i系列90-30遠程背板IC693CHS399 RX3i通用背板IC695CHS012 RX3i擴展背板IC694CHS392系列90-30遠程背板IC693CHS393 I/O終端插頭IC693ACC307最大電纜長度：15米（50英尺）最大電纜長度為213米（700英尺）圖7：使用擴展和遠程背板的RX3i系統PACSystems*RX3i《系統手冊》第3節GFK-2314T 2019年9月安裝19第2節：安裝本章提供安裝PACSystems RX3i設備的一般說明。? 安裝前檢查? 系統布局指南? 附件? 系統接線? 系統接地? 系統安裝有關系統安裝的其他信息，請參閱以下內容：? 第3章，背板，背板尺寸圖? 第4章，電源，電源規格和接線圖? 模塊接線圖和規范的第5章至第16章? 第17章了解一些高密度模塊的接線板、接線板快速連接系統（TBQC）和互連電纜的信息。? 通用標準信息附錄A? 附錄B關于計算散熱的信息? 附錄C有關電纜夾緊組件2.1安裝前檢查的信息收到RX3i設備后，仔細檢查所有裝運集裝箱是否損壞。如果系統的任何部分損壞，請立即通知承運人。損壞的運輸集裝箱應保存作為承運人檢查的證據。作為收貨人，您有責任向承運人登記運輸過程中發生的損壞索賠。但是，如果有必要，我們將與您充分合作。RX3i設備開箱后，記錄所有序列號。如果您在保修期內需要聯系客戶服務，則需要序列號。如果需要運輸或裝運系統的任何部分，則應保存所有裝運集裝箱和所有包裝材料。確認系統的所有組件均已收到，并且與您的訂單一致。如果收到的系統與您的訂單不一致，請聯系客戶服務部。如果您需要技術幫助，請聯系技術支持。有關電話號碼和電子郵件地址，請參閱聯系信息。PACSystems*RX3i系統手冊第3節GFK-2314T 2019年9月安裝20 2.2系統布局指南良好的布局有助于最大限度地減少系統工作人員觸電的機會。它使維護技術人員能夠方便地訪問設備進行測量、加載軟件、檢查指示燈、拆除和更換模塊等。它還使在進行故障排除時更容易追蹤布線和定位部件。此外，適當?shù)南到y(tǒng)布局可促進良好的散熱，并有助于消除系統中的電氣噪聲。過熱和噪音是電子元件故障的兩個主要原因?！鞂X3i設備放置在遠離產生大量熱量的其他部件的位置，如變壓器、電源或功率電阻器?！鞂X3i設備置于遠離產生電氣噪聲的部件（如繼電器和觸點）的位置?！鞂X3i設備放置在遠離高壓部件和電線的位置，如斷路器和易熔斷開器、變壓器和電機電線?！鞂⒃O(shè)備放置在方便的位置，使技術人員能夠合理地維護系統。
5: RX3i System using One Universal Backplane and One Expansion Backplane 1.5.2 Using Multiple Expansion and Remote Backplanes The next two example systems are similar to each other except for the distance between the backplanes. The example on the left includes two RX3i Expansion Backplanes and a Series 90-30 Expansion Backplane. The Expansion Backplanes can be any combination of RX3i (IC694) and Series 90-30 (IC693) Expansion Backplanes. I/O modules in the system can be any combination of RX3i and Series 90-30 modules. In the example on the right, two of the backplanes must be installed beyond the 15 m (50-ft) limit of an Expansion system. Two Series 90-30 Remote Backplanes are used in those locations. All other features of the two example systems are the same, including their I/O modules. PACSystems* RX3i System Manual Section 2 GFK-2314T Sept. 2019 Introduction 18 RX3i Expansion Backplane IC694CHS398 RX3i Universal Backplane IC695CHS012 RX3i Expansion Backplane IC694CHS392 Series 90-30 Expansion Backplane IC693CHS392 I/O Terminator Plug IC693ACC307 Maximum Cable Length: 15 meters (50 feet) Figure 6: RX3i System using Multiple Expansion Backplanes Series 90-30 Remote Backplane IC693CHS399 RX3i Universal Backplane IC695CHS012 RX3i Expansion Backplane IC694CHS392 Series 90-30 Remote Backplane IC693CHS393 I/O Terminator Plug IC693ACC307 Maximum Cable Length: 15 meters (50 feet) Maximum Cable Length: 213 meters (700 feet) Figure 7: Rx3i System using Expansion and Remote Backplanes PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 19 Section 2: Installation This chapter provides general instructions for installing PACSystems RX3i equipment. ? Pre-Installation Check ? System Layout Guidelines ? Enclosures ? System Wiring ? System Grounding ? System Installation For additional information about system installation, refer to the following: ? Chapter 3, Backplanes, for backplane dimension diagrams ? Chapter 4, Power Supplies, for power supply specifications and wiring diagrams ? Chapters 5 through 16 for module wiring diagrams and specifications ? Chapter 17 for information about terminal blocks for some higher-density modules, the Terminal Block Quick Connect System (TBQC) and interconnect cables. ? Appendix A for general standards information ? Appendix B for information about calculating heat dissipation ? Appendix C for information about the Cable Clamping Assembly 2.1 Pre-Installation Check Upon receiving your RX3i equipment, carefully inspect all shipping containers for damage. If any part of the system is damaged, notify the carrier immediately. The damaged shipping container should be saved as evidence for inspection by the carrier. As the consignee, it is your responsibility to register a claim with the carrier for damage incurred during shipment. However, we will fully cooperate with you, should such action be necessary. After unpacking the RX3i equipment, record all serial numbers. Serial numbers are required if you should need to contact Customer Care during the warranty period. All shipping containers and all packing material should be saved should it be necessary to transport or ship any part of the system. Verify that all components of the system have been received and that they agree with your order. If the system received does not agree with your order, contact Customer Care. If you need technical help, contact Technical Support. For phone numbers and email addresses, refer to Contact Information. PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 20 2.2 System Layout Guidelines A good layout helps minimize the chance of electrical shock to personnel working on the system. It lets maintenance technicians easily access the unit to make measurements, load software, check indicator lights, remove and replace modules, etc. It also makes it easier to trace wiring and locate components while troubleshooting. In addition, proper system layout promotes good heat dissipation and helps eliminate electrical noise from the system. Excess heat and noise are two major causes of electronic component failure. § Locate RX3i equipment away from other components that generate a lot of heat, such as transformers, power supplies, or power resistors. § Locate RX3i equipment away from components that generate electrical noise such as relays and contacts. § Locate RX3i equipment away from high-voltage components and wiring, such as circuit breakers and fusible disconnects, transformers, and motor wiring. § Locate equipment at a convenient level that allows technicians reasonable access for maintaining the system.
