RELIANCE 45C201遠程I/O處理器
在顯示財產窗口中選擇設置選項卡，然后單擊顯示類型按鈕。21.在“顯示類型”窗口中，單擊“更改”。22.在“更改顯示”窗口中，單擊“擁有磁盤”。23.將磁盤320-500052-002插入驅動器A24。單擊“確定”。25“芯片視頻加速器”將顯示在“更改顯示”窗口中。單擊“確定”。26。按照指示操作，從軟盤驅動器中取出驅動程序磁盤。重新啟動計算機以激活新設置。當系統重新啟動時，將顯示Invalid Display Settings（無效顯示設置）屏幕。單擊“確定”。27。在顯示財產屏幕上，單擊設置，然后單擊測試。28.將顯示測試模式屏幕。單擊Ok（確定）。如果位圖測試圖像顯示正確，請單擊Ok（確認）。該設備現在應配置為在Windows NT 4.0下運行。簡介VMIVME-7740以與其他PC/AT兼容計算機相同的方式使用BIOS（基本輸入/輸出系統）。本附錄描述了與VMIVME-7740 BIOS相關的菜單和選項。System BIOS Setup Utility（系統BIOS設置實用程序）在系統引導期間，按F2鍵訪問Phoenix BIOS主屏幕。在此屏幕中，用戶可以選擇Phoenix（系統）BIOS的任何部分進行配置，例如軟盤驅動器配置或系統內存。本節中顯示的參數為默認值。
Select the Settings tab in the Display Properties window, then click the Display Type button. 21. In the Display Type window, click Change. 22. In the Change Display window, click Have Disk. 23. Insert disk 320-500052-002 into drive A. 24. Click OK. 25. ‘Chips Video Accelerators’ will be displayed in the Change Display window. Click OK. 26. Proceed as directed, removing the driver disk from the floppy drive. Restart the computer to activate the new settings. When the system reboots, the Invalid Display Settings screen will be displayed. Click OK. 27. On the Display Properties screen click on Settings, then click Test. 28. The Testing Mode screen will be displayed. Click Ok. If the bitmap test image is displayed correctly, click OK. The unit should now be configured for operation under Windows NT 4.0 Introduction The VMIVME-7740 utilizes the BIOS (Basic Input/Output System) in the same manner as other PC/AT compatible computers. This appendix describes the menus and options associated with the VMIVME-7740 BIOS. System BIOS Setup Utility During system bootup, press the F2 key to access the Phoenix BIOS Main screen. From this screen, the user can select any section of the Phoenix (system) BIOS for configuration, such as floppy drive configuration or system memory. The parameters shown throughout this section are the default values.
