HIMA F3331通訊模塊
1.產 品 詳 情 資 料：
檢測到F（故障）/紅色單元錯誤。由控制軟件控制。在控制器復位期間由硬件進行設置和清除。R（un）/綠色運行。由控制軟件控制。在控制器復位過程中被硬件清除。100MBit/s開啟當Rx-Tx/黃色閃爍時，建立100 MBit/s的有效連接。100MBit/s關閉當Rx-Tx/黃色閃爍時，建立10 MBit/s的有效連接。RxTx指示燈亮起建立到相應以太網設備的鏈路。未發送/接收以太網包RxTx/黃色閃爍建立到相應以太網設備的鏈路。發送/接收以太網包。RxTx LED熄滅與相應以太網單元的鏈路未建立PRIM黃色LED，用于指示冗余配置中的主單元。DUAL黃色LED指示冗余配置。鍵入以太網單元。協議基金會現場總線高速以太網，TCP/IP。IEEE 802.3 100baseTX中定義的通信速度為10 Mbit/s/100 Mbit/s。狀態指示燈正常運行：綠色。異常故障：紅色。一個流量指示器-RxTx-由流量速度控制。連接器RJ45電流消耗（來自CEX總線24 V DC）100 mA典型值（最大150 mA）。功耗2.4 W典型值。根據EN60529和IEC 529，防護等級為IP20。
F(ault) /Red Unit error detected. Controlled by Control Software. Set and cleared by the hardware during controller Reset. R(un) /Green Operating. Controlled by the Control Software. Cleared by the hardware during controller Reset. 100MBit/s is ON A valid connection with100 MBit/s is established when Rx Tx/Yellow is flashing. 100MBit/s is OFF A valid connection with10 MBit/s is established when Rx Tx/Yellow is flashing. RxTx LED is ON A link to the corresponding Ethernet device is established. No Ethernet packages are sent/received RxTx/Yellow flashing A link to the corresponding Ethernet device is established. Ethernet packages are sent/received. RxTx LED is OFF A link with the corresponding Ethernet unit is not established PRIM A yellow LED for indicating the primary unit in redundant configuration. DUAL The yellow LED indicates the redundant configuration.Type Ethernet unit. Protocol FOUNDATION Fieldbus High Speed Ethernet, TCP/IP. Communication speed 10 Mbit/s / 100 Mbit/s defined in IEEE 802.3 100baseTX. Status indicators Running normally: Green. Exceptional fault: Red. One traffic indictor - RxTx - controlled by traffic pace. Connector RJ45 Current consumption (from CEX-Bus 24 V DC) 100 mA typical (150 mA max.). Power dissipation 2.4 W typical. Protection Rating IP20 according to EN60529, IEC 529.
2.產 品 展 示
3.公 司 優 勢 主 營 產 品
4.相 關 產 品 展 示
