B&R 5AP1120.156B-000觸摸控制器
1.產 品 資 料 介 紹：
中文資料：
5AP1120.156B -000是B&R AP1000 系列中的自動化面板。它具有15.6" 顯示屏尺寸，配備采用模擬電阻式技術的單點觸控觸摸屏。該觸摸屏具有81% ±3% 的透光率，并具有支持硬件校準的貝加萊觸摸控制器。面板的顯示屏具有LED 背光，具有半亮度時間為70,000 小時，可調光亮度在40 cd/m2和400 cd/m2之間。由于其高清顯示屏分辨率為 1366 x 768 像素，投影的圖像具有令人印象深刻的細節。這款貝加萊面板的框架由涂層鋁制成，并配有一個3 毫米的內置墊圈。
5AP1120.156B-000顯示屏上的熱傳感器可監控面板溫度并保護面板免受過載損壞。根據 UL 50，其前部僅支持 Type 4X 室內使用。面板的這一部分具有IP 65的防護等級，這意味著它不會被水射流噴霧穿透。它還具有防塵和防觸摸功能。背面防護等級為 IP 20，只能防止直徑超過 12 毫米的固體外部材料進入。操作AP1000面板所需的標稱電壓為24V DC，允許誤差為±25%，其標稱電流為3A。
英文資料：
5AP1120.156B-000 is an automation panel in the B&R AP1000 series. It has a 15.6 "display screen size and is equipped with a single touch touch screen using analog resistive technology. The touch screen has a transmittance of 81% ± 3% and a Baccarat touch controller that supports hardware calibration. The panel's display screen has LED backlight, a half brightness time of 70000 hours, and adjustable brightness of 40 cd/m 2 And 400 cd/m 2 between. Due to its high-definition display resolution of 1366 x 768 pixels, the projected images have impressive details. The frame of this Baccarat panel is made of coated aluminum and comes with a 3mm built-in washer.
The thermal sensor on the 5AP1120.156B-000 display screen can monitor panel temperature and protect the panel from overload damage. According to UL 50, its front only supports Type 4X indoor use. This part of the panel has IP 65 protection, which means it will not be penetrated by water jet spray. It also has dust and touch resistant functions. The back protection level is IP 20, which can only prevent solid external materials with a diameter exceeding 12 millimeters from entering. The nominal voltage required to operate the AP1000 panel is 24V DC, with an allowable error of ± 25%, and its nominal current is 3A.
2.產 品 展 示
