ICS TRIPLEX T9110處理器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ICS Triplex T9110 處理器模塊是 ICS Triplex（現為 Schneider Electric）的安全儀表和控制系統的一部分，專為關鍵任務和高安全性應用設計。該模塊常用于石油、天然氣、電力、化工等高風險行業，支持處理復雜的控制任務并提供強大的安全保障。
主要特點
高可靠性和安全性
- 設計用于安全控制，滿足 SIL 3（安全完整性等級3）要求，確保系統的高可靠性。
- 具有冗余設計，能夠在發生單點故障時繼續運行，保障系統不間斷服務。
高性能計算能力
- 強大的處理能力，支持快速響應和高效執行控制邏輯。
- 配備多個處理核心和高速數據總線，適應高吞吐量的數據處理需求。
冗余和容錯設計
- 支持 CPU 冗余，可實現主備切換，確?？刂葡到y(tǒng)的高可用性。
- 支持系統模塊的熱插拔，減少系統停機時間并增加系統維護靈活性。
多種輸入/輸出選項
- 支持多種 I/O 模塊的擴展，可以根據實際需求配置不同類型的輸入輸出設備。
- 支持模擬、數字、熱電偶、RTD 等多種信號輸入。
靈活的網絡和通信能力
- 提供多種通信接口，包括以太網（Ethernet）、Modbus、Profibus 等。
- 通過冗余網絡和通訊接口支持高可用性和數據傳輸可靠性。
集成式安全功能
- 內置多種自診斷和故障檢測功能，實時監控系統的健康狀態。
- 可以與外部設備（如泄漏檢測器、火災報警系統等）實現集成，增強整體安全性。
模塊化設計
- 支持與 Triplex 其他控制和監控模塊（如 T9150 和 T9170 系列）兼容，便于系統擴展。
- 易于與現有系統集成，支持不同的工業協議和標準。
技術參數
處理器
- 高性能 RISC 處理器，具有多核設計和高頻率，支持實時數據處理。
內存
- RAM：用于實時數據緩存和處理。
- 存儲：內置閃存，用于存儲程序和日志文件。
電源要求
- 工作電壓：24V DC（通過冗余電源供電）。
通信接口
- Ethernet（用于與其他模塊和系統的通信）。
- RS-485 或 Modbus 通訊接口，支持現場設備和外部系統的集成。
- 支持多種工業協議，如 HART、Profibus 等。
冗余設計
- 支持主/備 CPU 冗余，熱備份切換不影響系統運行。
- 支持冗余電源設計，確保設備在電源故障情況下持續運行。
環境條件
- 工作溫度：-20°C 至 60°C。
- 濕度：5% 至 95% RH（無冷凝）。
- 工作高度：可用于高海拔環境，支持海拔最高 2000 米。
尺寸
- 標準機架設計，支持 DIN 導軌安裝。
英文資料：
The ICS Triplex T9110 processor module is part of the safety instrumented and control system of ICS Triplex (now Schneider Electric), designed specifically for critical tasks and high safety applications. This module is commonly used in high-risk industries such as petroleum, natural gas, electricity, and chemical, supporting the handling of complex control tasks and providing strong security guarantees.
main features
High reliability and safety
Designed for safety control, meeting SIL 3 (Safety Integrity Level 3) requirements to ensure high system reliability.
With redundant design, it can continue to operate in the event of a single point of failure, ensuring uninterrupted service of the system.
High performance computing capability
Powerful processing capability, supporting fast response and efficient execution of control logic.
Equipped with multiple processing cores and high-speed data buses to meet high-throughput data processing requirements.
Redundant and fault-tolerant design
Support CPU redundancy, enable primary backup switching, and ensure high availability of the control system.
Support hot plugging of system modules to reduce system downtime and increase system maintenance flexibility.
Multiple input/output options
Supports expansion of multiple I/O modules and can configure different types of input/output devices according to actual needs.
Supports various signal inputs such as analog, digital, thermocouple, RTD, etc.
Flexible network and communication capabilities
Provide multiple communication interfaces, including Ethernet, Modbus, Profibus, etc.
Support high availability and data transmission reliability through redundant networks and communication interfaces.
Integrated security features
Built in multiple self diagnostic and fault detection functions, real-time monitoring of the system's health status.
It can be integrated with external devices such as leak detectors, fire alarm systems, etc. to enhance overall security.
Modular design
Supports compatibility with other Triplex control and monitoring modules (such as T9150 and T9170 series) for easy system expansion.
Easy to integrate with existing systems, supporting different industrial protocols and standards.
technical parameter
processor
High performance RISC processor with multi-core design and high frequency, supporting real-time data processing.
Memory
RAM: Used for real-time data caching and processing.
Storage: Built in flash memory for storing programs and log files.
Power requirements
Working voltage: 24V DC (powered by redundant power supply).
communication interface
Ethernet (used for communication with other modules and systems).
RS-485 or Modbus communication interface, supporting integration of field devices and external systems.
Supports multiple industrial protocols, such as HART, Profibus, etc.
Redundant design
Supports primary/backup CPU redundancy, and hot backup switching does not affect system operation.
Support redundant power supply design to ensure continuous operation of equipment in case of power failure.
environment condition
Working temperature: -20 ° C to 60 ° C.
Humidity: 5% to 95% RH (non condensing).
Working altitude: Suitable for high-altitude environments, supporting altitudes up to 2000 meters.
size
Standard rack design, supporting DIN rail installation.
2.產 品 展 示
