B&R 7AT664.70數字量輸出模塊，7AT664.70使用過程
MVME172LX安裝了172Bug固件。對于固件要與電路板一起正常工作，必須遵循以下步驟在下面在通電的情況下插入或卸下電路板可能會損壞電路板組件。1、關閉所有設備電源。參考MVME172LX第1-4頁的配置和標題上的跳線配置為對于您的特定應用程序是必要的。a、 標頭J21的跳線塊包含八個位，它們都是影響B(tài)ug操作。它們作為寄存器讀取（在位置$FFF4202D）。
B&R 7AT664.70數字量輸出模塊（MVME172 VME嵌入式控制器程序員參考指南包含有關MC2chip的其他信息。）當對應的跳線為時，位值讀取為0已安裝，或在拆下跨接導線時為1。MVME172LX上J21的默認配置為安裝了七條跳線（針腳9-10之間沒有跳線）。172Bug固件保留/定義四個低階位（GPI3到GPI0）。表2-2描述了J21上的位分配。b、 通過在兩個接頭之間安裝/拆卸跨接導線來配置收割臺J1針腳1和2。安裝/拆除跳線可啟用/禁用MVME172LX上的系統控制器功能。2.有關詳細信息，請參閱特定機箱或系統的設置程序有關MVME172LX安裝的詳細信息。3、連接用作系統的終端控制臺上的串行端口1處的默認調試EIA-232-D端口MVME172LX的前面板。請參閱中的串行連接第1章了解其他連接選項。將終端設置為跟隨：–每個字符8位–每個字符一個停止位–奇偶校驗禁用（無奇偶校驗）–波特率9600波特（MVME172LX端口的默認波特率通電時）通電后，您可以重新配置調試端口的波特率通過使用172Bug端口格式（PF）命令。
The MVME172LX comes with 172Bug firmware installed. For the
firmware to operate properly with the board, you must follow the steps
below. Inserting or removing boards with power applied may damage
board components.
1. Turn all equipment power OFF. Refer to MVME172LX
Configuration on page 1-4 and configure jumpers on headers as
necessary for your particular application.
a. The jumper block for header J21 contains eight bits, which all
affect 172Bug operation. They are read as a register (at location
$FFF4202D) on the MC2chip ASIC. (The MVME172 VME
Embedded Controller Programmer’s Reference Guide contains
additional information on the MC2chip.)
The bit values are read as a 0 when the corresponding jumper is
installed, or as a 1 when the jumper is removed.
The default configuration for J21 on the MVME172LX has
seven jumpers installed (no jumper between pins 9-10).
The 172Bug firmware reserves/defines the four lower order bits
(GPI3 to GPI0). Table 2-2 describes the bit assignments on J21.
b. Configure header J1 by installing/removing a jumper between
pins 1 and 2. A jumper installed/removed enables/disables the
system controller function on the MVME172LX.
2. Refer to the setup procedure for your particular chassis or system for
details concerning the installation of the MVME172LX. 3. Connect the terminal that is to be used as the 172Bug system
console to the default debug EIA-232-D port at serial port 1 on the
front panel of the MVME172LX. Refer to Serial Connections in
Chapter 1 for other connection options. Set the terminal up as
follows:
– Eight bits per character
– One stop bit per character
– Parity disabled (no parity)
– Baud rate 9600 baud (default baud rate of MVME172LX ports
at powerup)
After power-up, you can reconfigure the baud rate of the debug port
by using the 172Bug Port Format (PF) command.
