Solving Startup Problems
In the event of difficulty with your MVME172LX VME embedded
controller, try the simple troubleshooting steps on the following pages
before calling for help or sending the board back for repair. Some of the
procedures will return the board to the factory debugger environment. (The
board was tested under these conditions before it left the factory.) The selftests may not run in all user-customized environments.Network Controller Modules Supported
The 172Bug firmware supports following VMEbus network controller
modules. The default address for each module type and position is shown
to indicate where the controller must reside to be supported by the 172Bug.
The controllers are accessed via the specified CLUN and DLUNs listed
here. The CLUN and DLUNs are used in conjunction with the debugger
For additional information, refer to the following table for manufacturers’
data sheets or user’s manuals. As a further help, sources for the listed
documents are also provided. Please note that in many cases, the
information is preliminary and the revision levels of the documents are
subject to change without noticeRelated Specifications
For additional information, refer to the following table for manufacturers’
data sheets or user’s manuals. As a further help, sources for the listed
documents are also provided. Please note that in many cases, the
information is preliminary and the revision levels of the documents are
subject to change without notice.NOTE: An earlier version of the VME specification is available as:
Versatile Backplane Bus: VMEbus1. Disconnect all power from your system.
2. Check that the proper debugger device is installed.
3. Remove the jumper from J21, pins 9-10. This enables use of the
EPROM instead of the Flash memory.
4. Reconnect power.
5. Restart the system by “double-button reset”: press the RESET
and ABORT switches at the same time; release RESET first, wait
seven seconds, then release ABORT.
6. If the debug prompt appears, go to step IV or step V, as
indicated. If the debug prompt does not appear, go to step VI.
