System Considerations
The MVME177 draws power from both P1 and P2 of the VMEbus
backplane. P2 is also used for the upper 16 bits of data for 32-bit
transfers, and for the upper 8 address lines for extended addressing
mode. The MVME177 will not operate properly unless its main
board is connected to P1 and P2 of the VMEbus backplane.
Whether the MVME177 operates as a VMEbus master or as a
VMEbus slave, it is configured for 32 bits of address and for 32 bits
of data (A32/D32). However, it handles A16 or A24 devices in the
address ranges indicated in Chapter 3. D8 and/or D16 devices in the
system must be handled by the MC68060 software. Refer to the
memory maps in Chapter 3.
The MVME177 contains shared onboard DRAM whose base
address is software-selectable. Both the onboard processor and
offboard VMEbus devices see this local DRAM at base physical
address $00000000, as programmed by the MVME177Bugfirmware. This may be changed, by software, to any other base
address. Refer to the Single Board Computers Programmer's Reference
Guide for details.
If the MVME177 attempts to access offboard resources in a
nonexistent location, and is not system controller, and if the system
does not have a global bus time-out, the MVME177 waits forever for
the VMEbus cycle to complete. This causes the system to hang up.
There is only one situation in which the system might lack this
global bus time-out:
? The MVME177 is not the system controller, and
? There is no global bus time-out elsewhere in the system
Multiple MVME177 modules may be configured into a single VME
card cage. In general, hardware multiprocessor features are
supported.
Other MPUs on the VMEbus can:
? Interrupt
? Disable
? Communicate with, and
? Determine the operational status of
the processor(s). One register of the GCSR set includes four bits
which function as location monitors to allow one MVME177
processor to broadcast a signal to other MVME177 processors, if
any. All eight registers are accessible from any local processor as
well as from the VMEbus.
The MVME177 provides +12 Vdc power to the Ethernet LAN
transceiver interface through a 1 amp polyswitch F2 located on the
MVME177 module. The +12V LED lights when +12 Vdc is
available. The polyswitch is located near diode CR1. Polyswitches
act like circuit breakers that reset automatically when the excessive
load is removed. If the Ethernet transceiver fails to operate, check
