Introduction
The EIA-232-D standard is the most widely used
terminal/computer and terminal/modem interface, and yet it is
not fully understood. This may be because not all the lines are
clearly defined, and many users do not see the need to follow the
standard in their applications. Often designers think only of their
own equipment, but the state of the art is computer-to-computer or
computer-to-modem operation. A system should easily connect to
any other system.
The EIA-232-D standard was originally developed by the Bell
System to connect terminals via modems. Several handshaking
lines were included for that purpose. Although handshaking is
unnecessary in many applications, the lines themselves remain part
of many designs because they facilitate troubleshooting.
Table A-1 lists the standard EIA-232-D interconnections. To
interpret this information correctly, remember that EIA-232-D was
intended to connect a terminal to a modem. When computers are
connected to each other without modems, one of them must be
configured as a terminal (data terminal equipment: DTE) and the
other as a modem (data circuit-terminating equipment: DCE). Since
computers are normally configured to work with terminals, they
are said to be configured as a modem in most cases.
Signal levels must lie between +3 and +15 volts for a high level, and
between -3 and -15 volts for a low level. Connecting units in parallel
may produce out-of-range voltages and is contrary to EIA-232-D
specifications.Notes:
1. A high EIA-232-D signal level is +3 to +15 volts. A low level is -3
to -15 volts. Connecting units in parallel may produce out-of-range
voltages and is contrary to specifications.
2. The EIA-232-D interface is intended to connect a terminal to a
modem. When computers are connected without modems, one
must be configured as a modem and the other as a terminal.
Levels of Implementation
There are several levels of conformance that may be appropriate for
typical EIA-232-D interconnections. The bare minimum
requirement is the two data lines and a ground. The full
implementation of EIA-232-D requires 12 lines;
