GE IC3600SOSF燃?xì)廨啓C(jī)控制模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE IC3600SOSF 是一款燃?xì)廨啓C(jī)控制模塊，屬于 GE 的 Speedtronic 系列產品，專為燃?xì)廨啓C(jī)系統設計，執行關鍵的監測和控制任務。以下是該模塊的詳細信息：
產品概述
GE IC3600SOSF 燃?xì)廨啓C(jī)控制模塊通過接收傳感器輸入信號并輸出控制命令，確保燃?xì)廨啓C(jī)的高效、安全和可靠運行。其功能涵蓋燃料管理、溫度控制和轉速調節等關鍵控制領域。
核心功能
燃?xì)饬髁靠刂?/strong>：
- 管理燃?xì)廨斎?，確保燃料供給與負載需求匹配。
溫度監測與保護：
- 通過實時監測燃?xì)廨啓C(jī)溫度，提供過熱保護功能，避免設備損壞。
轉速調節：
- 調節燃?xì)廨啓C(jī)的轉速，以適應不同的運行條件和功率需求。
信號處理：
- 接收并處理來自溫度傳感器、壓力傳感器和速度傳感器的信號，將其轉換為控制系統所需的標準信號。
邏輯控制：
- 執行復雜的邏輯算法，確保燃?xì)廨啓C(jī)的穩定運行。
技術規格
輸入信號：
- 支持模擬信號輸入，例如溫度、壓力和轉速信號。
- 數字信號輸入，用于狀態監測和安全保護。
輸出信號：
- 提供模擬或數字控制信號，用于燃?xì)忾y門、點火裝置或其他執行機構。
電源要求：
- 工作電壓：24V DC 或 48V DC（根據系統配置）。
環境條件：
- 工作溫度：-20°C 至 +70°C。
- 濕度范圍：0%-95%（無冷凝）。
接口與連接：
- 標準化的多針接口，適用于 GE Speedtronic 系統的模塊化安裝。
英文資料：
GE IC3600EPSA1A is a frequency converter module belonging to GE's Speedtronic control system series, designed for turbine control and other industrial automation applications. The following is detailed information about the IC3600EPSA1A inverter board:
Product Features
Core functions:
Realize voltage or frequency regulation for controlling motor speed and output power.
Supports variable frequency drive for AC motors, suitable for various industrial applications.
Design features:
Modular design, compatible with the standard framework of GE Speedtronic system.
Onboard various electronic components, including power transistors, capacitors, resistors, and transformers, to achieve efficient frequency conversion.
Integrated control circuit ensures the stability and accuracy of frequency regulation.
Interface and Connection:
Standardized multi pin pin design for quick installation and replacement.
Provide input ports to receive control signals, and output ports to drive loads.
Reliability:
Industrial grade design, suitable for harsh environments such as high temperature, high humidity, and vibration.
Equipped with overload protection and short circuit protection functions to enhance system safety.
technical specifications
Input voltage: typically 24V or 48V DC (matching system configuration).
Output characteristics:
Adjustable output frequency range: 0 Hz to 400 Hz.
Maximum output current: customized according to specific applications and system requirements.
Control type:
Support PWM (Pulse Width Modulation) technology to achieve efficient frequency control.
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Size and weight:
Compliant with the standard modular dimensions of the Speedtronic system.
Lightweight and easy to install and maintain.
2.產 品 展 示
