GE IC3600AOAH1放大器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE IC3600AOAH1 是一款放大器卡（Amplifier Card），隸屬于 GE 的 Speedtronic 系列，主要用于信號處理和放大。該模塊被廣泛應用于渦輪機控制系統中，以增強和穩定從傳感器或其他設備接收到的輸入信號，從而確保系統運行的準確性和可靠性。
產品特點
信號放大：
- 提供高增益放大功能，用于提升弱信號的強度，使其適合后續的處理和控制。
多通道設計：
- 支持多路信號的并行處理，適合復雜系統的多點監測需求。
信號濾波：
- 集成濾波電路，減少噪聲和干擾，確保輸出信號的穩定性。
模塊化設計：
- 標準化插卡結構，可直接安裝到 Speedtronic 系統的背板中，便于維護和替換。
技術規格
輸入電壓：
- 支持標準低電平信號輸入（通常在毫伏或伏特范圍內）。
輸出電壓：
- 放大后的信號輸出，范圍通常為 0-10V 或 4-20mA（具體根據系統要求）。
增益范圍：
- 可調節增益，通常范圍為 1x 到 100x。
信號帶寬：
- 支持高達 20kHz 的信號放大。
工作環境：
- 溫度范圍：-20°C 至 +70°C。
- 濕度范圍：0%-95%（無冷凝）。
尺寸與接口：
- 標準化尺寸，與 GE Speedtronic 系統兼容。
- 提供多針連接器，確保穩定的電氣接觸。
英文資料：
GE IC3600AOAH1 is an amplifier card belonging to GE's Speedtronic series, mainly used for signal processing and amplification. This module is widely used in turbine control systems to enhance and stabilize input signals received from sensors or other devices, ensuring the accuracy and reliability of system operation.
Product Features
Signal amplification:
Provide high gain amplification function to enhance the strength of weak signals, making them suitable for subsequent processing and control.
Multi channel design:
Supports parallel processing of multiple signals, suitable for multi-point monitoring requirements of complex systems.
Signal filtering:
Integrated filtering circuit reduces noise and interference, ensuring the stability of the output signal.
Modular design:
Standardized card insertion structure, which can be directly installed into the backplane of the Speedtronic system for easy maintenance and replacement.
technical specifications
Input voltage:
Supports standard low-level signal input (usually in the millivolt or volt range).
Output voltage:
The amplified signal output typically ranges from 0-10V or 4-20mA (depending on system requirements).
Gain range:
Adjustable gain, typically ranging from 1x to 100x.
Signal bandwidth:
Supports signal amplification up to 20kHz.
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Size and interface:
Standardized dimensions, compatible with GE Speedtronic system.
Provide multi pin connectors to ensure stable electrical contact.
